Tektronix MDO34 User Manual

Logic Trigger - Define Inputs configuration menu
Use this menu to set the signal sources, logic states, and threshold levels to use for the Logic trigger
.
To open the Logic Trigger - Define Inputs configuration menu:
1. Double-tap the Trigger badge on the Settings bar.
2. Set Trigger Type to Logic.
3. Tap the Logic Pattern Define Inputs button.
Logic Trigger - Define Inputs configuration menu fields and controls
Field or control Description
Chx (analog channels) or Dx
(digital channels)
Use to select the signal source's logic condition on which to perform the logic trigger (High, Low,
Don't Care). T
ap to select.
If a channel is a digital channel, tap the + symbol to open the list of digital inputs (D0-D7) from which to
select individual logic conditions for the digital signals.
Use the Threshold field to set the signal level that must be exceeded for that signal to be true (logical
1).
Set All Sets all signal sources to detect a logic High, Low, or Don't Care condition.
Pulse W
idth Trigger configuration menu
Use the Pulse Width Trigger to trigger on specific pulse width conditions, including when a pulse width is within or outside a range of
specified times. Pulse Width triggers are often used to troubleshoot digital signals.
To open the Pulse Width trigger configuration menu:
1. Double-tap the Trigger badge on the Settings bar.
2. Set the Trigger Type to Pulse Width.
Settings panel (Pulse Width Trigger configuration menu) fields and controls
Field or control Description
Source
Lists the source channel or waveform to use to trigger.
Trigger When
• < Limit: A pulse width is less than the specified time limit.
• > Limit: A pulse width is greater than the specified time limit.
• = Limit: A pulse width is equal to the specified time limit.
• ≠ Limit: A pulse width does not equal (is greater than or less than) the specified time limit.
• Inside Range: A pulse width is in the specified time range.
• Outside Range: A pulse width is outside of the specified time range.
Level Sets the amplitude level that the signal must pass through to be considered a valid transition.
Table continued…
Menus and dialog boxes
3 Series Mixed Domain Oscilloscope Printable Help 218

Tektronix MDO34 Specifications

General

Analog Channels	4
Sample Rate	2.5 GS/s
Record Length	10 Mpoints
Mixed Domain Analysis	Yes
Waveform Capture Rate	>280, 000 wfms/s
Spectrum Analyzer Frequency Range	9 kHz to 3 GHz
Vertical Resolution	8 bits
Input Coupling	AC, DC, GND
Operating Temperature	0°C to +50°C
Digital Channels	16
Connectivity	USB, LAN, HDMI
Arbitrary Function Generator	50 MHz
Trigger Types	Edge, Pulse Width, Runt, Logic, Setup/Hold, Rise/Fall Time, Video
Input Impedance	1 MΩ
Maximum Input Voltage	300 Vrms
Dimensions	140 mm
Weight	4.5 kg
Bandwidth	100 MHz, 200 MHz, 350 MHz, 500 MHz
Display	10.1-inch capacitive touch HD display
Voltmeter	4-digit
