Tektronix MDO34 User Manual

Field or control Description
Source Select the source waveform from the drop-down list. Default is the selected waveform.
Cursor A X-Position Set a specific x-axis position for Cursor A using the multipurpose knob, or double-tap to set the
position using the keypad.
Cursor B X-Position Set a specific x-axis position for Cursor B using the multipurpose knob, or double-tap to set the
X-Position using the keypad.
Cursor Mode Select the cursor mode. This is only available in time domain mode.
Independent mode sets multipurpose knobs A and B to move each cursor separately (default).
Linked mode sets multipurpose knob A to move both cursors at the same time. Knob B will still move
cursor B independently of knob A.
Readout Selects the readout mode, Abosolute or Delta. Delta readouts are relative to the Reference Marker.
This is only available in frequency domain mode.
Date and Time configuration menu
Use this menu to set the date, time, and UTC of
fset.
To open the Date and Time configuration menu, double-tap on the Date/Time badge in the lower-right corner of the oscilloscope display.
Date and Time configuration menu fields and controls
Field or control Description
Display Toggles display of the date and time On or Off.
When turned of
f, tap on the blank area below the Status badge, in the lower-right corner of the
oscilloscope display, to open the configuration menu and set display to On.
Year Use the multipurpose knob to set the year.
Month Select from the list.
Day Use the multipurpose knob to set the day
Hour Use the multipurpose knob to set the hour.
Minute Use the multipurpose knob to set the minute.
UTC Offset Use the multipurpose knob to set the offset.
Ok, Set Date & Time Applies your date and time settings.
Digital channel configuration menu
Use the Digital channel menu to enable individual digital channels, set their thresholds, and add labels.
T
o open the Digital channel configuration menu, double-tap a Digital channel badge. You can also double-tap on the digital channel
handles to open the menu.
Menus and dialog boxes
3 Series Mixed Domain Oscilloscope Printable Help 173

Tektronix MDO34 Specifications

General

Analog Channels	4
Sample Rate	2.5 GS/s
Record Length	10 Mpoints
Mixed Domain Analysis	Yes
Waveform Capture Rate	>280, 000 wfms/s
Spectrum Analyzer Frequency Range	9 kHz to 3 GHz
Vertical Resolution	8 bits
Input Coupling	AC, DC, GND
Operating Temperature	0°C to +50°C
Digital Channels	16
Connectivity	USB, LAN, HDMI
Arbitrary Function Generator	50 MHz
Trigger Types	Edge, Pulse Width, Runt, Logic, Setup/Hold, Rise/Fall Time, Video
Input Impedance	1 MΩ
Maximum Input Voltage	300 Vrms
Dimensions	140 mm
Weight	4.5 kg
Bandwidth	100 MHz, 200 MHz, 350 MHz, 500 MHz
Display	10.1-inch capacitive touch HD display
Voltmeter	4-digit
