Field or control Description
Cancel Closes the keypad without saving entered values.
Waveform View configuration menu
Use this menu to configure the W
aveform View to set style, persistence, intensity, markers, spectrogram, and other parameters.
To open the Waveform View menu, double-tap anywhere in the Waveform View screen.
Time Domain Waveform View menu fields and controls
Fields or controls Description
Persistence Sets the length of time data points are displayed on screen before being erased.
Off sets the record points to appear for the current acquisition only
.
Infinite continuously accumulates record points on the waveform until you change one of the
acquisition display settings or clear the acquisition memory. Use infinite persistence for displaying
record points that may occur outside the normal acquisition envelope.
Variable lets you specify a time length to retain data points on screen. Each record point decays
independently according to the time interval.
Auto sets the Waveform Intensity field to control the persistence time.
Variable Persistence Time
(Persistence = Variable)
Sets the length of time data points remain displayed. Tap the field and use the A knob to adjust, or
double-tap and use the keypad to set a time.
Waveform Style Sets how waveforms are drawn on the screen.
Vectors draws waveforms with lines between record points.
Dots draws waveform record points as dots on the screen, and adds crosshair markers to real
sampled points.
Table continued…
Menus and dialog boxes
3 Series Mixed Domain Oscilloscope Printable Help 230

Tektronix MDO34 Specifications

General

Analog Channels	4
Sample Rate	2.5 GS/s
Record Length	10 Mpoints
Mixed Domain Analysis	Yes
Waveform Capture Rate	>280, 000 wfms/s
Spectrum Analyzer Frequency Range	9 kHz to 3 GHz
Vertical Resolution	8 bits
Input Coupling	AC, DC, GND
Operating Temperature	0°C to +50°C
Digital Channels	16
Connectivity	USB, LAN, HDMI
Arbitrary Function Generator	50 MHz
Trigger Types	Edge, Pulse Width, Runt, Logic, Setup/Hold, Rise/Fall Time, Video
Input Impedance	1 MΩ
Maximum Input Voltage	300 Vrms
Dimensions	140 mm
Weight	4.5 kg
Bandwidth	100 MHz, 200 MHz, 350 MHz, 500 MHz
Display	10.1-inch capacitive touch HD display
Voltmeter	4-digit
