Field or control Description
Addressing Mode Sets the slave device address length (7 bits or 10 bits long).
Only available when Mark On = Address or Address & Data.
Address Sets the address pattern for which to search. The number of bits shown depends on the Address
Mode setting.
T
ap the Binary or Hex field and use the A and B knobs to select and change the values. Or double-tap
on the field and use the virtual keypad to enter values.
Only available when Mark On = Address or Address & Data.
Data Bytes Sets the number of data bytes for which to search (one to five bytes). Use the A knob to change the
value.
Only available when Mark On = Data or Address & Data.
Data Sets the data pattern for which to search. The number of bits shown depends on the Data Bytes
setting.
Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or double-tap
on the field and use the virtual keypad to enter values.
Only available when Mark When = Data or Address & Data.
A, B knob controls Use the A knob to select (highlight) the character to change.
Use the B knob to change the value of the character.
Or double-tap the field and use the virtual keypad to enter the data. See Binary, decimal, hex, and
octal virtual keypads on page 228.
Copy Trigger Settings to
Search
Sets the search criteria to match the current oscilloscope trigger settings. If the trigger settings are not
valid in Search, this control is either not available or grayed out.
Copy Search Settings to
Trigger
Sets the current oscilloscope trigger settings to match the search criteria.
LIN serial bus search configuration menu
Use the LIN Search configuration menu to define conditions to search for and mark on an LIN bus waveform.
Note: Requires option SRAUT
O.
Field or control Description
Display Enables or disables displaying search marks on this search.
Table continued…
Menus and dialog boxes
3 Series Mixed Domain Oscilloscope Printable Help 144
