Setup and Hold Search - Define Inputs configuration menu
Use the Define Inputs menu to select the data signal source(s) and set their threshold level(s).
To open the Setup & Hold Search - Define Inputs menu:
1. Double-tap a Setup & Hold Search badge on the Results bar.
2. Tap the Data Sources > Define Inputs button.
Setup and Hold Search - Define Inputs configuration menu fields and controls
Field or control Description
Ch(x) (analog channels) or
D(x) (digital Channels
Use to add (Include) or exclude (Don't Include) the data signal(s) from available input channels and
waveforms.
If a channel is a digital channel, tap the + symbol to open the list of digital inputs (D15-D8 or D0-D7)
from which to select for that channel.
Use the Threshold fields to set the signal level that must be exceeded for the signal transition to be
true.
Set All Use to Include or Don't Include all available channels and waveforms as data signals.
Timeout Search configuration menu
Use the T
imeout search to mark a waveform when it does not detect an expected pulse transition within a specified period of time, such as
when a signal gets stuck either high or low.
To create a new timeout search:
1. Tap Search.
2. Set the Search Type to Timeout.
3. Select the search Source.
4. Use the menu fields to set the search parameters.
To change the settings on an existing search, double-tap the search badge and make necessary changes.
Timeout Search menu fields and controls
Menus and dialog boxes
3 Series Mixed Domain Oscilloscope Printable Help 160
