Factory options
The 3 Series MDO is configured according to the various options you choose when you purchase your instrument. All options in this
section are installed at the factory.
Bandwidth options
The table lists the different bandwidth configuration options for your 3 Series MDO.
Table 1: 3 Series bandwidth options
Option name Description
3-BW-100 100 MHz Bandwidth for analog channels
3-BW-200 200 MHz Bandwidth for analog channels
3-BW-350 350 MHz Bandwidth for analog channels
3-BW-500 500 MHz Bandwidth for analog channels
3-BW-1000 1 GHz Bandwidth for analog channels
Digital channels option
The MSO option provides 16 digital channels to simultaneously view analog and digital signals on your oscilloscope.
Table 2: 3 Series MSO option
Option name Description
3-MSO Adds 16 digital channels to the oscilloscope. The option includes a P6316 digital probe and
accessories.
Spectrum analyzer frequency range options
The spectrum analyzer options increase the input frequency range and capture bandwidth of the integrated spectrum analyzer
. With
increased spectrum analyzer bandwidth you can capture higher-frequency signals and view a broader spectrum. The 1 GHz spectrum
analyzer comes standard on all models. The 3 GHz spectrum analyzer is optional.
Table 3: 3 Series spectrum analyzer options
Option name Description
3-SA3 Increase spectrum analyzer input frequency range to 9 kHz to 3 GHz and capture bandwidth to 3 GHz
Arbitrary Function Generator (AFG) option
The AFG option adds a 50 MHz AFG function to your oscilloscope.
AFG features
•
Function types: Arbitrary, Sine, Square, Pulse, Ramp, Triangle, DC Level, Gaussian, Lorentz, Exponential Rise/Fall, Sin(x)/x, Random
Noise, Haversine, Cardiac
• Maximum frequency: 50 MHz (Sine)
• Maximum output amplitude: 5 Vp-p
• Maximum sample rate: 250 MS/s
Factory options
3 Series Mixed Domain Oscilloscope Printable Help 25

Tektronix MDO34 Specifications

General

Analog Channels	4
Sample Rate	2.5 GS/s
Record Length	10 Mpoints
Mixed Domain Analysis	Yes
Waveform Capture Rate	>280, 000 wfms/s
Spectrum Analyzer Frequency Range	9 kHz to 3 GHz
Vertical Resolution	8 bits
Input Coupling	AC, DC, GND
Operating Temperature	0°C to +50°C
Digital Channels	16
Connectivity	USB, LAN, HDMI
Arbitrary Function Generator	50 MHz
Trigger Types	Edge, Pulse Width, Runt, Logic, Setup/Hold, Rise/Fall Time, Video
Input Impedance	1 MΩ
Maximum Input Voltage	300 Vrms
Dimensions	140 mm
Weight	4.5 kg
Bandwidth	100 MHz, 200 MHz, 350 MHz, 500 MHz
Display	10.1-inch capacitive touch HD display
Voltmeter	4-digit
