Tektronix MDO34 User Manual

After entering the password you can do the following:
•
Change your password
• Enable or disable the I/O ports
• Enable or disable firmware updates
Enter Password configuration menu fields and controls
Field or control Description
Enter Password Enter the password. The valid range of characters for the password is from one to 32 characters.
Entering no characters or more than 32 characters results in an error message.
Note: If the instrument has a keyboard attached, and you have disabled the USB ports,
double-tap on the password field to open the virtual keyboard and enter the password.
Change Password Use the displayed controls to change to a new password.
I/O Ports (USB, LAN) After entering the password, tap to toggle the I/O ports on or off.
Firmware Updates After entering the password, tap to enable/disable firmware updates.
Set Password configuration menu (optional)
Use this function to set the password used to access the optional security functions. This menu is only shown on instruments with optional
security functions installed.
T
o access the Set Password configuration menu:
1. Tap Utility in the Menu bar.
2. Tap Security.
3. Tap Advanced to open the Advanced panel.
4. Tap Set Password.
5. In the New Password field, enter the new password.
6. In the Repeat New Password field, enter the new password.
7. Tap Set New Password to set the password and close the menu.
Set Password menu fields and controls
5
Field or control Description
Set Password
Opens the dialog for changing the password.
6
Password Enter the new password.
Repeat Password Reenter the new password.
Set New Password After entering the new password, tap Set Password to set the password and close the dialog.
I/O Ports (USB, LAN) After entering the password, tap to toggle I/O Ports on or off.
Firmware Updates After entering the password, tap to enable/disable firmware updates..
5
If the instrument has a keyboard attached, and you have disabled the USB ports, double-tap on the password field to open the virtual keyboard and enter the
password.
6
The valid range of characters for the password is from one to 32 characters. Entering no characters or more than 32 characters results in an error message.
Menus and dialog boxes
3 Series Mixed Domain Oscilloscope Printable Help 190

Tektronix MDO34 Specifications

General

Analog Channels	4
Sample Rate	2.5 GS/s
Record Length	10 Mpoints
Mixed Domain Analysis	Yes
Waveform Capture Rate	>280, 000 wfms/s
Spectrum Analyzer Frequency Range	9 kHz to 3 GHz
Vertical Resolution	8 bits
Input Coupling	AC, DC, GND
Operating Temperature	0°C to +50°C
Digital Channels	16
Connectivity	USB, LAN, HDMI
Arbitrary Function Generator	50 MHz
Trigger Types	Edge, Pulse Width, Runt, Logic, Setup/Hold, Rise/Fall Time, Video
Input Impedance	1 MΩ
Maximum Input Voltage	300 Vrms
Dimensions	140 mm
Weight	4.5 kg
Bandwidth	100 MHz, 200 MHz, 350 MHz, 500 MHz
Display	10.1-inch capacitive touch HD display
Voltmeter	4-digit
