SPI serial bus configuration menu on page 131
RS-232 serial bus menu on page 129
CAN serial bus configuration menu on page
120
LIN serial bus configuration menu on page 124
FlexRay serial bus configuration menu on page 122
Audio serial bus configuration menu on page 118
USB serial bus configuration menu on page 132
MIL-STD-1553 serial bus menu on page 126
ARINC429 serial bus menu on page 117
See also
Bus Trigger configuration on page 199
Bus Search configuration menus on page 135
Parallel Bus configuration menu
Use this menu to set up and display a parallel bus waveform. Parallel bus decoding and triggering is included with the oscilloscope.
To set up the parallel bus:
• To create a new parallel bus, tap the Add Math, Ref, Bus button on the Settings bar and select Bus. Open the bus configuration menu
by double clicking on the badge. Set the Bus Type to Parallel.
• To change the settings on an existing parallel bus waveform, double-tap the Bus waveform badge to open the configuration menu, and
make necessary changes.
Parallel bus configuration menu fields and controls
Field or control Description
Display Turns on or off displaying the bus in the Waveform view.
Label Enter a label for the bus. The default label is the selected bus type.
T
o enter label text, double-tap the field and enter label using the virtual keyboard, or tap the field and
enter text from an attached keyboard.
Bus Type Set to Parallel to define a parallel bus.
Clocked Data Toggles Yes or No to use a clock signal to recover the data bits from the bus inputs.
Clock Source Sets the source for the bus clock signal. The source can be an analog or digital channel.
This field is only available when Clocked Data is set to Yes.
Table continued…
Menus and dialog boxes
3 Series Mixed Domain Oscilloscope Printable Help 127
