Tektronix MDO34 User Manual

Field or control Description
Copy Trigger Settings to
Search
Sets the search criteria to match the current oscilloscope trigger settings. If the trigger settings are not
valid in Search, this control is either not available or grayed out.
Copy Search Settings to
T
rigger
Sets the current oscilloscope trigger settings to match the search criteria.
FlexRay serial bus search configuration menu
Use the FlexRay Search configuration menu to define conditions to search for and mark on a FlexRay bus waveform.
Note: Requires option SRAUT
O.
Field or control Description
Display Enables or disables displaying search marks on this search.
Source Select the FlexRay bus for which to search.
Mark On Select the type of information for which to search.
Indicator Bits Select the defined indicator bits type for which to search from the drop-down list: Normal (01XX),
Payload (1
1XX), Null (00XX), Sync (XX10), or Startup (XX11).
Only available when Mark On = Indicator Bits.
Indicator Bits Enter the indicator bits for which to search.
Tap the Binary, Hex, or Decimal field and use the A and B knobs to select and change the values. Or
double-tap on the field and use the virtual keypad to enter values.
Only available when Mark On = Header Fields.
Identifier Enter the frame identifier pattern for which to search.
Tap the Binary, Hex, or Decimal field and use the A and B knobs to select and change the values. Or
double-tap on the field and use the virtual keypad to enter values.
Only available when Mark On = Identifier & Data or Header Fields.
Cycle Count Enter the cycle count pattern for which to search. Use in conjunction with the Mark When field to
specify the exact search condition.
Tap the Binary, Hex, or Decimal field and use the A and B knobs to select and change the values. Or
double-tap on the field and use the virtual keypad to enter values.
Only available when Mark On = Cycle Count and Mark When Data is not set to Inside Range or
Outside Range .
Table continued…
Menus and dialog boxes
3 Series Mixed Domain Oscilloscope Printable Help 141

Tektronix MDO34 Specifications

General

Analog Channels	4
Sample Rate	2.5 GS/s
Record Length	10 Mpoints
Mixed Domain Analysis	Yes
Waveform Capture Rate	>280, 000 wfms/s
Spectrum Analyzer Frequency Range	9 kHz to 3 GHz
Vertical Resolution	8 bits
Input Coupling	AC, DC, GND
Operating Temperature	0°C to +50°C
Digital Channels	16
Connectivity	USB, LAN, HDMI
Arbitrary Function Generator	50 MHz
Trigger Types	Edge, Pulse Width, Runt, Logic, Setup/Hold, Rise/Fall Time, Video
Input Impedance	1 MΩ
Maximum Input Voltage	300 Vrms
Dimensions	140 mm
Weight	4.5 kg
Bandwidth	100 MHz, 200 MHz, 350 MHz, 500 MHz
Display	10.1-inch capacitive touch HD display
Voltmeter	4-digit
