Tektronix MDO34 User Manual

Field or control Description
ESI Bit Sets the ESI bit state for which to search.
Only available when Mark On = FD ESI Bits.
Identifier Format Sets the identifier for Standard (11-bit) or Extended (29-bit for CAN 2.0B) length.
Only available when Mark On = Identifier or ID & Data.
Identifier Sets the identifier pattern for which to search. The number of bits shown depends on the Identifier
Format setting.
T
ap the Binary or Hex field and use the A and B knobs to select and change the values. Or double-tap
on the field and use the virtual keypad to enter values.
Only available when Mark On = Identifier or ID & Data.
Search When Data Sets the data to search for.
Only available when Mark On = Identifier or ID & Data.
Data Bytes Sets the number of data bytes for which to search (one to eight bytes). Use the A knob to change the
value.
Only available when Mark On = Data or Identifier & Data .
Data Offset Sets the data offset in bytes to delay the trigger. Use the A knob to change the value.
Only available when Mark On = Data or Identifier & Data .
Data Sets the data pattern for which to search. The number of bits shown depends on the Data Bytes
setting.
Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or double-tap
on the field and use the virtual keypad to enter values.
Only available when Mark On = Data or Identifier & Data .
A, B knob controls Use the A knob to select (highlight) the digit to change.
Use the B knob to change the value of the digit.
Or double-tap the field and use the virtual keypad to enter the data. See Binary, decimal, hex, and
octal virtual keypads on page 228.
Table continued…
Menus and dialog boxes
3 Series Mixed Domain Oscilloscope Printable Help 140

Tektronix MDO34 Specifications

General

Analog Channels	4
Sample Rate	2.5 GS/s
Record Length	10 Mpoints
Mixed Domain Analysis	Yes
Waveform Capture Rate	>280, 000 wfms/s
Spectrum Analyzer Frequency Range	9 kHz to 3 GHz
Vertical Resolution	8 bits
Input Coupling	AC, DC, GND
Operating Temperature	0°C to +50°C
Digital Channels	16
Connectivity	USB, LAN, HDMI
Arbitrary Function Generator	50 MHz
Trigger Types	Edge, Pulse Width, Runt, Logic, Setup/Hold, Rise/Fall Time, Video
Input Impedance	1 MΩ
Maximum Input Voltage	300 Vrms
Dimensions	140 mm
Weight	4.5 kg
Bandwidth	100 MHz, 200 MHz, 350 MHz, 500 MHz
Display	10.1-inch capacitive touch HD display
Voltmeter	4-digit
