Tektronix MDO34 User Manual

Field or control Description
Payload Length Enter the payload length pattern for which to search. Use in conjunction with the Mark On field to
specify the exact search condition.
T
ap the Binary, Hex, or Decimal field and use the A and B knobs to select and change the values. Or
double-tap on the field and use the virtual keypad to enter values.
Only available when Mark On = Header Fields.
Header CRC Enter the header CRC pattern for which to search. Use in conjunction with the Mark On field to specify
the exact search condition.
Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or double-tap
on the field and use the virtual keypad to enter values.
Only available when Mark On = Header Fields.
Data Bytes Enter the number of data bytes for which to search (one to sixteen bytes). Use the A knob to change
the value.
Only available when Mark On = Data or Identifier & Data.
Data Enter the data pattern for which to search. The number of bits shown depends on the Data Bytes
setting. Use in conjunction with the Mark On field to specify the exact search condition.
Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or double-tap
on the field and use the virtual keypad to enter values. See Binary, decimal, hex, and octal virtual
keypads on page 228.
Only available when Mark On = Data or Identifier & Data and Mark When Data is not set to Inside
Range or Outside Range.
Data Low, Data High
Sets the boundary data conditions when testing for in-range or out of range conditions.
Available when Mark On = Data or Identifier & Data and Mark When Data is set to Inside Range or
Outside Range.
Data Offset Sets the data offset (Don't Care or the number of bytes). Tap the field and use the A knob to change
the value.
Only available when Mark On = Data or Identifier & Data.
Table continued…
Menus and dialog boxes
3 Series Mixed Domain Oscilloscope Printable Help 142

Tektronix MDO34 Specifications

General

Analog Channels	4
Sample Rate	2.5 GS/s
Record Length	10 Mpoints
Mixed Domain Analysis	Yes
Waveform Capture Rate	>280, 000 wfms/s
Spectrum Analyzer Frequency Range	9 kHz to 3 GHz
Vertical Resolution	8 bits
Input Coupling	AC, DC, GND
Operating Temperature	0°C to +50°C
Digital Channels	16
Connectivity	USB, LAN, HDMI
Arbitrary Function Generator	50 MHz
Trigger Types	Edge, Pulse Width, Runt, Logic, Setup/Hold, Rise/Fall Time, Video
Input Impedance	1 MΩ
Maximum Input Voltage	300 Vrms
Dimensions	140 mm
Weight	4.5 kg
Bandwidth	100 MHz, 200 MHz, 350 MHz, 500 MHz
Display	10.1-inch capacitive touch HD display
Voltmeter	4-digit
