Tektronix MDO34 User Manual

Field or control Description
Label High Sets the high value of the label pattern range for which to search.
T
ap the Binary or Hex field and use the A and B knobs to select and change the values. Or double-tap
on the field and use the virtual keypad to enter values.
Available when Mark When = Label and Mark When Label = Inside Range or Outside Range.
Mark When Data Sets the data condition for which to search.
Available when Mark On = Label & Data or Data.
Data Sets the data pattern for which to search.
Tap the Binary, Hex, or Octal field and use the A and B knobs to select and change the values. Or
double-tap on the field and use the virtual keypad to enter values.
Available when Mark When Data ≠ Inside Range or Outside Range.
Data Low , Data High
Sets the boundary data conditions when testing for in-range or out of range conditions.
Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or double-tap
on the field and use the virtual keypad to enter values.
Available when Mark When Data = Inside Range or Outside Range.
SSM Sets the Sign/Status Matrix (SSM) bit condition for which to search.
Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or double-tap
on the field and use the virtual keypad to enter values.
Available when Mark On = Data and the Data Format control in the bus definition is set to Data (19
bits) or SDI + Data (21 bits).
SDI Sets the Source/Destination Identifier (SDI) bit condition for which to search.
Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or double-tap
on the field and use the virtual keypad to enter values.
Available when Mark On = Data and the Data Format control in the bus definition is set to Data (19
bits).
Table continued…
Menus and dialog boxes
3 Series Mixed Domain Oscilloscope Printable Help 137

Tektronix MDO34 Specifications

General

Analog Channels	4
Sample Rate	2.5 GS/s
Record Length	10 Mpoints
Mixed Domain Analysis	Yes
Waveform Capture Rate	>280, 000 wfms/s
Spectrum Analyzer Frequency Range	9 kHz to 3 GHz
Vertical Resolution	8 bits
Input Coupling	AC, DC, GND
Operating Temperature	0°C to +50°C
Digital Channels	16
Connectivity	USB, LAN, HDMI
Arbitrary Function Generator	50 MHz
Trigger Types	Edge, Pulse Width, Runt, Logic, Setup/Hold, Rise/Fall Time, Video
Input Impedance	1 MΩ
Maximum Input Voltage	300 Vrms
Dimensions	140 mm
Weight	4.5 kg
Bandwidth	100 MHz, 200 MHz, 350 MHz, 500 MHz
Display	10.1-inch capacitive touch HD display
Voltmeter	4-digit
