Field or control Description
Address Sets the token packet address pattern for which to search. Use in conjunction with the Mark When
field to specify the exact search condition.
T
ap the Binary, Hex, or Decimal field and use the A and B knobs to select and change the values. Or
double-tap on the field and use the virtual keypad to enter values.
Only available when Mark On ≠ Inside Range or Outside Range.
Token Type Sets the token packet type for which to search.
Only available when Mark On = Token Packet.
Endpoint Sets the token packet endpoint pattern for which to search. Use in conjunction with the Mark When
field to specify the exact search condition.
Tap the Binary, Hex, or Decimal field and use the A and B knobs to select and change the values. Or
double-tap on the field and use the virtual keypad to enter values.
Only available when Mark On = Token Packet and Token Type = all except SOF (0101).
Frame Number Sets the frame number pattern for which to search. Use in conjunction with the Mark When field to
specify the exact search condition.
Tap the Binary, Hex, or Decimal field and use the A and B knobs to select and change the values. Or
double-tap on the field and use the virtual keypad to enter values.
Only available when Mark On = Token Packet and Token Type = SOF (0101).
Data Packet Type Sets the data packet type for which to search.
Only available when Mark On = Data Packet.
Data Bytes Sets the number of data bytes for which to search (one to sixteen bytes). Tap the field and use the A
knob to change the value.
Only available when Mark On = Data Packet.
Data Offset Sets the data offset (Don't Care or the number of bytes). Tap the field and use the A knob to change
the value.
Only available when Mark On = Data Packet.
