Tektronix MDO34 User Manual

Field or control Description
Address Sets the address pattern on which to trigger.
T
ap the Binary, Hex, or Dec field and use the A and B knobs to select and change the values. Or
double-tap on the field and use the virtual keypad to enter values.
Available when Trigger When RT Address = anything but Inside Range or Outside Range.
High Address Sets the high address of the address pattern range on which to trigger.
Tap the Binary, Hex, or Dec field and use the A and B knobs to select and change the values. Or
double-tap on the field and use the virtual keypad to enter values.
Available when Trigger When RT Address = Inside Range or Outside Range.
Low Address Sets the low value of the address pattern range on which to trigger.
Tap the Binary, Hex, or Dec field and use the A and B knobs to select and change the values. Or
double-tap on the field and use the virtual keypad to enter values.
Available when Trigger When RT Address = Inside Range or Outside Range.
Subaddress/Mode Sets the subaddress or mode pattern on which to trigger.
Tap the Binary, Hex, or Dec field and use the A and B knobs to select and change the values. Or
double-tap on the field and use the virtual keypad to enter values.
Available when Trigger On = Command.
Word Count/Mode Code Sets the word count or mode code on which to trigger.
Tap the Binary, Hex, or Dec field and use the A and B knobs to select and change the values. Or
double-tap on the field and use the virtual keypad to enter values.
Available when Trigger On = Command.
Status Word Bits Sets the status word pattern on which to trigger.
Tap the Binary, Hex, or Dec field and use the A and B knobs to select and change the values.
Selecting a bit shows a short description of that bit's function. Or double-tap on the field and use the
virtual keypad to enter values.
Available when Trigger On = Status.
A, B knob controls Use the A knob to select (highlight) the digit(s) to change in data or bit fields.
Use the B knob to change the value of the digit(s). Or double-tap on the field and use the virtual
keypad to enter values.
Mode & Holdoff
Trigger Mode determines how the instrument behaves in the absence or presence of a trigger event.
Holdoff sets the amount of time the oscilloscope waits after a trigger event before detecting and
triggering on the next trigger event.
For additional information on Trigger Mode, Holdoff, forcing a trigger, and the Trigger Frequency
Counter see Mode and Holdoff panel on page 226.
Act On Trigger
Set the actions the instrument takes when a trigger event occurs.
For additional information on the Act On Trigger panel see Act On Trigger configuration
menu on page 227.
Menus and dialog boxes
3 Series Mixed Domain Oscilloscope Printable Help 210

Tektronix MDO34 Specifications

General

Analog Channels	4
Sample Rate	2.5 GS/s
Record Length	10 Mpoints
Mixed Domain Analysis	Yes
Waveform Capture Rate	>280, 000 wfms/s
Spectrum Analyzer Frequency Range	9 kHz to 3 GHz
Vertical Resolution	8 bits
Input Coupling	AC, DC, GND
Operating Temperature	0°C to +50°C
Digital Channels	16
Connectivity	USB, LAN, HDMI
Arbitrary Function Generator	50 MHz
Trigger Types	Edge, Pulse Width, Runt, Logic, Setup/Hold, Rise/Fall Time, Video
Input Impedance	1 MΩ
Maximum Input Voltage	300 Vrms
Dimensions	140 mm
Weight	4.5 kg
Bandwidth	100 MHz, 200 MHz, 350 MHz, 500 MHz
Display	10.1-inch capacitive touch HD display
Voltmeter	4-digit
