Tektronix MDO34 User Manual

Field or control Description
Error Type Sets the error type on which to trigger.
A
vailable when Trigger On = Error.
Address Sets the token packet address pattern on which to trigger. Use in conjunction with the Trigger When
field to specify the exact trigger condition.
Tap the Binary, Hex, or Decimal field and use the A and B knobs to select and change the values. Or
double-tap on the field and use the virtual keypad to enter values.
Available when Trigger When ≠ Inside Range or Outside Range.
Address Low, Address High Sets the boundary address conditions when testing for in-range or out of range conditions.
Available when Trigger When = Inside Range or Outside Range.
Frame Number Sets the frame number on which to trigger. Use in conjunction with the Trigger When field to specify
the exact trigger condition.
Tap the Binary, Hex, or Dec field and use the A and B knobs to select and change the values. Or
double-tap on the field and use the virtual keypad to enter values.
Available when Trigger When = Token Packet and Token Type = SOF (0101).
Data Packet Type Sets the data packet type on which to trigger.
Available when Trigger On = Data Packet.
Data Bytes Sets the number of data bytes on which to trigger (one to two bytes). Tap the field and use the A knob
to change the value.
Available when Trigger On = Data Packet.
Byte Offset Sets the byte offset (Don't Care or the number of bytes). Tap the field and use the A knob to change
the value.
Available when Trigger On = Data Packet.
Data Sets the data packet pattern on which to trigger. The number of bits shown depends on the Data
Bytes setting. Use in conjunction with the Trigger When field to specify the exact trigger condition.
Tap the Binary, Hex, or ASCII field and use the A and B knobs to select and change the values. Or
double-tap on the field and use the virtual keypad to enter values. See Binary, decimal, hex, and octal
virtual keypads on page 228.
Available when Trigger On = Data Packet and Trigger When = anything but Inside Range or
Outside Range.
Data Low, Data High Sets the boundary data conditions when testing for in-range or out of range conditions.
Available when Trigger When = Inside Range or Outside Range.
A, B knob controls Use the A knob to select (highlight) the digit(s) to change.
Use the B knob to change the value of the digit(s).
Table continued…
Menus and dialog boxes
3 Series Mixed Domain Oscilloscope Printable Help 214
