TDS5000 Series User Manual
3-49
Triggering
To use the oscilloscope to sample a signal and digitize it into a waveform record
that you want to process, you need to set up the trigger conditions. This section
provides background on and procedures for using the basic elements of
triggering:
H Trigger Concepts: Basic principles of triggering including type, source,
coupling, holdoff, mode, and so on.
H Triggering from the Front Panel: Using the front-panel triggering controls.
H Additional Trigger Parameters: Accessing common trigger functions in the
Trigger Setup control window.
H Advanced Triggering: Trigger types that you can use to trigger the oscillo-
scope on specific conditions.
H Sequential Triggering: Combining the A (Main) and B (Delayed) trigger
systems to capture unique events.
Figure 3--19 shows how triggers fit into the overall oscilloscope operation.
Acquisition
system
Input
Display
Storage
Waveform
transform
system
Horizontal
time base
Trigger
Figure 3- 19: Oscilloscope System Overview: Triggering
