Appendix A: Specifications
TDS5000 Series User Manual
A-19
Table A- 8: Power source specifications
Characteristic Description
Source voltage and frequency 100 to 240 V ±10%,47Hzto63Hz
Power consumption ≤220 W
Overvoltage Category Overvoltage Category II (as defined in IEC61010-1/A2)
Table A- 9: Mechanical specifications
Characteristic Description
Weight
Benchtop configuration 22 lbs (10 kg) oscilloscope only
55 lbs (25 kg) when packaged for domestic shipm ent
Rackmount kit 4 lbs (1.8 kg) rackmount conversion kit
11 lbs (5 k g) kit packaged for domestic shipment
Dimensions
Benchtop configuration 11.2 in (284.5 mm) height ,
12.8 in (325.1 mm) with feet extended
17.6 in (447 mm) width
11.35 in (288.3 mm) depth
Rackmount configuration
(Option 1R)
10.5 in (267 mm) height
19 in (483 mm) width
11.35 in (288.3 mm) depth
Cooling Fan-forced air circulation with no air filter.
Required clearances Top 0in(0mm)
Bottom 0.25 in (6.5 mm) minimum
or 0 in (0 mm) when stand-
ing on the feet
Left side 3in(76mm)
Right side 0in
5 in (126 mm) required to
access CD-ROM
Front 0in(0mm)
Rear 0in(0mm)
Construction material Chassis parts are constructed of aluminum alloy, front
panel is constructed of plastic laminate, circuit boards are
constructed of glass laminate, outer shell is molded and
textured from a polycarbonate/ABS blend
