Creating and Using Math Waveforms
3- 168
TDS5000 Series User Manual
1
0
Amplitude
Time
--67 dB side lobe
0
-- 8 0
dB
Frequency bins
-- 4 0
Figure 3- 54: Time and frequency graphs for the Kaiser-Bessel window
