Appendix A: Specifications
TDS5000 Series User Manual
A-17
Table A- 6: Input/output por t specifications
Characteristic Description
Probe Compensator Output Front-panel terminals
Output voltage Frequency
1.0 V (from base t o top) ±
1.0% into a ≥ 10 kΩ load
1kHz± 5%
Analog Signal Output amplitude Rear-panel BNC connector, provides a buffered version of
the signal that is attached to the channel 3 input
20 mV/div ± 20%intoa1MΩ load
10 mV/div ± 20% into a 50 Ω load
Analog Signal Output bandwidth,
typical
100 MHz into a 50 Ω load
Auxiliary Output levels Rear-panel BNC connect or, provides a TTL-compatible,
negative-polarity pulse for each A or B trigger (select able)
V
out
high V
out
low (true)
≥2.5 V into open circuit,
≥1.0 V into 50 Ω load
≤0.7 V with ≤4masink,
≤0.25 V into 50 Ω load
Auxiliary Output pulse width, typical Pulse width varies, 1 s minimum
External Reference Input Rear-panel BNC connector
9.8 MHz to 10.2 MHz
200 mV p-p to 7 V p-p
>1.5kΩ in series with ~10 nf DC blocking capacitor
