TELOS TWOX12 USER’S MANUAL
DETAILED CONFIGURATION & REFERENCE
CHAPTER 7 103
7.2 Status Displays
Pressing the Status button displays the various status screens. These status screens
display information about the state of the Telos TWOx12 and various user settings,
but do not allow you to make any changes. The 5 & 6 buttons cycle through the
screens.
Line Status
This screen shows the status of the Telco channels. From here you can determine the
status of each Telco channel and whether the ISDN BRI or POTS circuit and the
TWOx12 are successfully configured. In addition, information about call status is
displayed here. One of the following status words will be shown for each channel
present:
Deactivated No line connected, or connected to wrong jack on the
TWOx12. OR, ETS 300 permits the Telco to put a line to
sleep. Deactivated will be displayed when this occurs. OR
system is currently testing for the presence of a POTS line
(ie looking for loop current)
Wait SPID has been sent to network (DMS Cust. And Natl I-1
only). Network has not approved SPID (SPID is incorrect).
Ready The unit sees a live ISDN S interface (ie external NT1 is
present or internal NT1 has completed startup). OR loop
current has been detected on a POTS line and the line has
been declared “in service” by the system.
Pending Seize Outgoing call in process; Request for call has been sent to
Telco switch. OR outgoing POTS call is pending – system if
“off-hook” and waiting for loop current.
Seized Outgoing call in process; Telco switch has acknowledged the
call request. OR Loop current has been detected on a POTS
line after going “off-hook”.
Call Proceeding Outgoing call in process; Telco switch waiting for routing info
from network.
Outgoing Ring Outgoing call in process; far end has generated a call alert
signal
Disconnecting Request to disconnect has been made. Awaiting
acknowledgment. OR POTS interface has gone “on-hook”
and system is waiting for loop current to cease.
Incoming Ring An incoming call request has been detected and is being
processed.
