Mute button
(Mute) – This button mutes the handset microphone and hands free microphone
on the Desktop Director™. The LED beside this button will light to indicate that
these microphones are muted. Pressing this button again will cancel the muting
function.
This button is unimplemented and therefore has no function!
4.3.3 User Function Buttons –
These buttons can be used for control of equipment external to the Telos phone
system. For instance the ?#@! button may used to control your obscenity delay
dump, etc.
For details on the output circuitry and pin-outs for these buttons see section 2.9.1.
(user button) – This button controls an output on the parallel control port. This
output will go low for the duration that the button is pressed. This output can control
equipment external to the TWOx12 such as the “delay dump” input on an obscenity
delay unit.
(Record Control) – This button is used in conjunction with an external
recorder. Pressing this button once cause the Record Start output (pin 3) on the
Parallel Control Port to go true for 1 second. The LED next to this button should now
illuminate.
Pressing the record control button again will cause the Record Stop output (pin 4) on
the Parallel Control Port to go true for 1 second. The LED next to this button should
now go out.
For details on the electrical characteristics of these outputs please see section 2.9.1.
