TELOS TWOX12 USER’S MANUAL
INSTALLATION
CHAPTER 2 44
7. Reconnect the Desktop Director cable and turn the unit upright
8. Check for proper operation
Desktop Director Assembly
Wire assembly
This should be fairly self explanatory. The black “curly cord” plugs into the handset. The
other end of this cord should be plugged into the small 4 position/4 pin modular (RJ-22
style) jack near the front left of the unit. This jack is identified with a picture of a telephone
handset and is the jack closer to the front of the Director. The second jack at this location
can be used to directly connect a telephone headset and is identified with a picture of a
headset. Route these cables through the small slots to the left so they do not interfere with
the unit sitting flat on the table.
h
HOT TIP!
We have tested, and recommend, the Plantronics model P51- U10P "Supra Polaris noise-
canceling unamplified monaural" or model P61- U10P "Supra Polaris noise- canceling
unamplified binaural " headsets for use with the Desktop Director. For the name of your
nearest Plantronics dealer contact them at 831 426- 5868 or www.plantronics.com.
When the headset is attached it will automatically mute the microphone of the handset to
prevent extraneous noise. Disconnecting the “quick-connect” inline connector on the
headset cable will re-enable the handset microphone.
Line Designation Strip
The Desktop Director ships with several pre-cut paper “designation strips” to allow
labeling the lines of the Director. Choose one and fill out the line numbers if desired (we
suggest a “Sharpie extra fine point” or similar fine point indelible marker). Place the paper
strip on the director and then cover with the clear plastic protector, inserting the plastic tabs
in the slots on the Director to hold it in place. Should you decide to change things later,
simply lift one end of the plastic and slide out the strip.
Mounting Options
The Desktop Director legs can be mounted in an alternative “upright” orientation. To do so,
remove the legs by removing the two Phillips head screws on each leg. The legs can then
be mounted in the alternative orientation using the same screws.
The Desktop Director can be mounted on a wall or other vertical surface. First remove the
legs by removing the two Phillips head screws on each leg. The unit can then be hung from
two screws on 5 inch (127 mm) centers. Care should be taken that the screws do not
protrude more than 1/8 inch (3 mm) from the mounting surface.
