TELOS TWOX12 USER’S MANUAL
INSTALLATION
CHAPTER 2 8
Since ISDN will be new to many users, sections 2.3 & 2.4 give an introduction to the
technology. If you are using analog telephone lines (POTS) you can skip those sections if
you wish.
As you read through this chapter connect your inputs and outputs. In section 3 we will
proceed with detailed system configuration issues.
System Configuration –
A “maxed out” TWOx12 includes the following:
"
4 Desktop Call Directors
"
6 ISDN BRI circuits (with 2 callers per BRI circuit)
OR, depending on the version ordered,
"
12 POTS analog telephone circuits (loop start)
"
1 dual channel AES/EBU send-to-caller digital mix-minus source
OR
"
2 send-to-caller analog mix-minus source(s)
"
1 dual channel AES/EBU Caller output
AND/OR
"
2 Analog caller outputs
"
1 program on hold analog source
Note that there are several configuration choices that you will be making in order to install
the system in a given facility. A diagram of the TWOx12’s inputs and outputs follows.
