TELOS TWOX12 USER’S MANUAL
GETTING UP & GOING – SYSTEM CONFIGURATION
CHAPTER 3 59
• Scroll down to TopDN/MSN2 and repeat the previous step, entering the second MSN
for the ISDN circuit in the top jack of slot A. If your line does not have MSNs you
must enter a unique 3 digit number here. Push Select to confirm.
• Scroll down to BotDN/MSN1 using the 6 button and repeat the previous step, entering
the first MSN for the ISDN circuit in the bottom jack of slot A. Push Select to
confirm.
• Scroll down to BotDN/MSN2 and repeat the previous step, entering the second MSN
for the ISDN circuit in the bottom jack of slot A. Push Select to confirm.
• Scroll up to the ↵ using the 5 button and press the Select button.
• Repeat the steps above to enter your MSNs for slots B and C, if needed.
• Power the unit off and then back on.
USA & Canada ISDN Setup
USA & Canada ISDN Setup USA & Canada ISDN Setup
USA & Canada ISDN Setup (users outside the USA & Canada should see the previous section):
• Press the TEL button
You will see a screen which looks like the following:
Audio Settings
Telco Natl.I-1
Slot A ISDN $
Slot B ISDN
$
Slot C ISDN
$
• Make sure the dark cursor bar is over Telco as shown (if not, use the 5 & 6 keys to
move the cursor) and press the Select button.
• Press the 5 or 6 button until the appropriate protocol is shown (see tips below) and
press the Select button again to confirm.
w
IMPORTANT!
Each ISDN Line has a certain ISDN protocol (or “switch type”) which the phone
company should have given you. By far the most common protocols in the USA &
Canada are National ISDN- 1 & National ISDN- 2 in which case you should set the
Telco setting to
Natl.I- 1
.
If you do not know what protocol your line is configured for, try
Natl.I- 1
first. If that
does not work see section 7.3.2 for hints on how to guess your protocol.
Telco Settin
g
s
