TELOS TWOX12 USER’S MANUAL
INSTALLATION
CHAPTER 2 24
PIN TIA 568A
COLOR
DESCRIPTION
1* White/Green PS 3 Power +/ground (Optional)
2* Green PS 3 Power – (Optional)
3 White/Orange Xmt (TE to NT1) to Network +
4 Blue Rcv (NT1 to TE) from Network +
5 White/Blue Rcv (NT1 to TE) from Network -
6 Orange Xmt (TE to NT1) to Network -
7@ White/Brown PS 2 Power 48 VDC – (Optional)
8@ Brown PS 2 Power +/ground (Optional)
*
@
Not used in Telos Products
Not used on the TWOx12
TIA 568ACategory 5 cable wiring diagram. Both ends are wired identically. Note that the S interface
does not require all 8 conductors.
h
HOT TIP
•
When fully wired, this cable has 4 twisted pairs wired “straight through” just like the
cables often used for Ethernet 10Base- T. The wiring configuration is the same as
TIA 568A (TIA- 568B is electrically equivalent, and can also be used).
•
Both ends are wired identically.
•
The outside pairs are generally not required and may be omitted.
The ISDN S interface on the Telos TWO does not provide power. Usually the Telecom
company will arrange for power to the NT1 (NTBA).
2.5.2 Integration with a PBX using ISDN
The TWOx12 has been used satisfactorily using BRI off the following PBX Switches used
in USA and Canada:
Nortel Meridian 2 wire (U interface) [User report]
Please contact Technical Support for the latest information or report you experiences with
other switches.
