TELOS TWOX12 USER’S MANUAL
GETTING UP & GOING – SYSTEM CONFIGURATION
CHAPTER 3 58
Worldwide ISDN Setup (
Worldwide ISDN Setup (Worldwide ISDN Setup (
Worldwide ISDN Setup (outside USA & Canada): (Users outside the USA & Canada
should skip this section)
• Press the TEL button
You will see a screen which looks like the following:
Audio Settings
Telco Natl.I-1
Slot A
$
Slot B $
Slot C $
• Make sure the dark cursor bar is over Telco as shown (if not use the 5 & 6 keys to
move the cursor) and press the Select button.
• Press the 5 button until ETS300 (or other appropriate protocol) is shown and press the
Select button again to confirm.
• Scroll down using the 6 button until you have highlighted SLOT A with the dark
cursor bar.
• Press the Select button. You will now see a screen which looks like:
Audio Settings
↵
Top SPID1
Top SPID2
TopDN/MSN1
• Scroll down using the 6 button until you have highlighted TopDN/MSN1 and press
the Select button. Enter your first MSN for the ISDN circuit in the top jack of slot A
using the numeric keypad. If you do not have a MSN you must ewnter a unique 3 digit
number here. If a number had been previously entered you may delete it one character
at a time by using the 5 button. Push Select again to confirm.
Telco Settin
g
s
Slot-A ISDN
