TELOS TWOX12 USER’S MANUAL
INSTALLATION
CHAPTER 2 11
2.2 Installation checklist (Copy this checklist and use it to help organize your installation)
We suggest you look through the rest of section 2 before proceeding. Then work through
this checklist as you prepare to install the TWOx12.
Will a PBX be used in conjunction with the TWOx12 installation?
NY
#$
Configure BRI ports on PBX. See section 2.5.2 and your
PBX vendor.
Bring ISDN BRI circuits to the location where the TWOx12 will located.
1 pair for each ISDN U interface (USA and Canada) or 2 pair for the ISDN S
interface (Worldwide). See section 2.5 for details.
How many mix-minuses (with send-to-caller audio) will be used? See “Routing”
210in section 7.3.1 (routing) for more on mix-minuses.
##$ If no mix-minus is available see information on feed thru mode in section
7.3.1. Note: Your program audio will pass through the TWOx12 in this case.
#
$ If only a single mix-minus will be available see “Routing” in section 7.3.1.
Bring 1 or 2 mix-minus audio feeds (AES/EBU, or –7 to +8 dBu analog) from your
# console to the TWOx12.
How many inputs on the console will be used?
21
# $ If only a single feed from the TWOx12 to the console will be used see
“Routing” in section 7.3.1 for information on your options.
Bring 1 or 2 of the Output (Caller) signals from the TWOx12 to your console.
#
Run one of the supplied Desktop Director cables from the TWOx12 to each of
# the locations where the Desktop Directors will be located. See section 2.7.
If more than two Desktop Directors will be used see section 2.7.
