TELOS TWOX12 USER’S MANUAL
CABLE GUIDE
APPENDIX 2 170
PIN COLOR
1 White/Green
2 Green
3 White/Orange
4Blue
5 White/Blue
6Orange
7 White/Brown
8Brown
TIA-568A color codes. Cat 5 cable Is used and both ends are Identical. The color conductor of
each pair may or may not have a white stripe. The other half of the pair may be either white or
white with a colored stripe.
Note that TIA-568B is electrically equivalent, however the Green and Orange pairs
are reversed as follows:
PIN COLOR
1 White/Orange
2Orange
3 White/Green
4Blue
5 White/Blue
6 Green
7 White/Brown
8Brown
TIA-568B color codes. Note that this is electrically Identical to TIA-568A, however the green and
orange pairs are switched.
