TELOS TWOX12 USER’S MANUAL
GETTING UP & GOING – SYSTEM CONFIGURATION
CHAPTER 3 66
w
IMPORTANT!
If you are using one of the routing schemes that requires only a single mix- minus you
should
not
have seen audio on either the “1” or “2” bargraphs in the previous test. In
that case you can skip the next test.
See section 7.3.1 for detailed information about the TWOx12’s routing options.
Now we will verify the second mix-minus.
• Press right Line 2 button to move the call made above to hybrid 2.
• Bring up hybrid 2 on the console. You will hear the audio from the phone line.
• Look at the left meter on the TWOx12 and verify that this audio is not present on
the “2” LED bargraph. If this audio is present here you are not feeding hybrid 2 a
mix-minus and you must fix this problem before you proceed.
• Drop the call by pushing the Drop button
.
Ok, now we just need to test the system as whole. We suggest calling your spouse or
partner and reporting that you will be home for dinner after all!
1. Confirm that the Desktop Director you will be using has power and says “Talent”
at the top of the screen. If it says “Producer” follow the directions in section 4.1.3
to change this Director to “Talent” mode.
2. Press the left Line 1 button to select that line for dialing. You should now hear dial
tone through the console (mixing desk).
3. Enter the phone number for the line you wish to call.
4. Bring up hybrid 1 on the console. You will hear the audio from the phone line.
5. Put on some headphones, bring up the microphone, and greet the party at the far
end.
6. Your voice should sound normal in your headphones, without any tinny or hollow
artifacts, and the caller should sound clear.
7. Move the call to Hybrid 2 by pressing the right Line 1.
8. Repeat steps 4 through 6 using hybrid 2.
