Table B-25. MSP-TS430PM64D Bill of Materials
Pos. Ref Des
No. per
Board
Description Digi-Key Part No. Comment
1 PCB 1 90x96 mm MSP-TS430PM64D Rev. 1.0 2 layers, 90x96mm, white solder
mask
2 BSL 1 10-pin connector, male, TH HRP10H-ND DNP, keep vias free of solder
3 D1 1 Green LED, HSMG-C170,
DIODE0805
516-1434-1-ND Avago, Farnell 5790852
4 D2, D3 2 LED, DIODE0805 DNP
5 JP2, JP3,
JP4
3 2-pin header, male, TH SAM1035-02-ND place jumper on header
6 JP1, JP5,
JP6, JP7,
JP8, JP9,
JP10
7 3-pin header, male, TH SAM1035-03-ND place jumpers on pins 2-3 (JTAG)
7 R1 1 330R, 0805 541-330ATR-ND
8 R5, R6 2 330R, 0805 541-330ATR-ND DNP
9 R2, R3,
R10, R11
4 0R, 0805 541-0.0ATR-ND DNP
10 R4 1 47K, 0805 311-47KARTR-ND
11 C1, C2 2 12pF, CSMD0805 709-1169-2-ND
12 C3 1 10uF/10V, CSMD0805 445-1371-2-ND
13 C4 1 100nF, CSMD0805 311-1245-2-ND
14 C6, C7, C8,
C9
4 100nF, CSMD0805 311-1245-2-ND DNP
15 C5 1 1.1nF, CSMD0805 490-1623-2-ND
16 J1, J2, J3,
J4
1 16-pin header, TH SAM1029-16-ND DNP: headers and receptacles,
enclosed with kit. Keep vias free
of solder.
17 J1, J2, J3,
J4
1 16-pin receptable, TH SAM1213-16-ND DNP: headers and receptacles,
enclosed with kit. Keep vias free
of solder.
18 JTAG 1 14-pin connector, male, TH HRP14H-ND
19 U1 1 Socket IC51-0644-807 Manuf.: Yamaichi
20 U1 2 MSP430FR4133IPM DNP: enclosed with kit. Is
supplied by TI.
21 J5 1 3-pin header, male, TH SAM1035-03-ND
22 Q1 1 Microcrystal 32768Hz, MS3V-
T1R (32.768kHz, 20ppm, 12.5pF)
23 SW1, SW2 2 Panasonic EVQ11 P8079STB-ND DNP, Lacon: 1251459
24 Rubber
stand off
4 Buerklin: 20H1724 apply to corners at bottom side
Hardware www.ti.com
106 MSP430™ Hardware Tools SLAU278AG – MAY 2009 – REVISED DECEMBER 2020
Submit Document Feedback
Copyright © 2020 Texas Instruments Incorporated
