Table B-43. MSP-TS430PZ100AUSB Bill of Materials
Pos. Ref Des No. Per Board Description Digi-Key Part No. Comment
1 PCB Rev. 1.1 1 99.65mm x 79.54mm 2 layers, red solder mask
2 C1, C2 2 12pF, SMD0805 DNP: C1, C2
3
C10, C12,
C17, C18
9 100nF, SMD0805 311-1245-2-ND DNP: C10, C12,C18, C17
4 C15 1 22nF, CSMD0805 311-1242-1-ND
5 C16 1 4.7 nF SMD0603 311-1250-1-ND
6 C3, C4 2 47pF, CSMD0805 709-1337-1-ND
7 C33, C38 2 220n SMD0603 Buerklin: 53D2074
8 C35, C36 2 10p SMD0603 Buerklin: 56D102
9 C39 1 4u7 SMD0603 Buerklin: 53D2086
10 C40 1 0.1u SMD0603 Buerklin: 53D2068
11
C5, C11, C13,
C14, C19
5 100nF, SMD0805 311-1245-2-ND
12 C6, C7 2 10uF/6.3V, Tantal Size B 511-1463-2-ND
13 C8 1 2.2nF, CSMD0805 709-1339-1-ND
14 C9 1 470nF, SMD0805 478-1403-2-ND
15 D1 1
green LED, HSMG-C170
DIODE0805
516-1434-1-ND Avago, Farnell 5790852
16 D2, D4 2 LL103A, SOD-80 Buerklin: 24S3406
17 IC7 1 TPD4E004DRYR 296-23618-1-ND Manu: TI
18 J1, J2, J3, J4 4 25-pin header, TH SAM1029-25-ND
DNP: Headers enclosed in kit.
Keep vias free of solder.
19 J1, J2, J3, J4 4 25-pin receptacle, TH SAM1213-25-ND
DNP: Receptacles enclosed in
kit. Keep vias free of solder.
20 J5 1 3-pin header, male, TH SAM1035-03-ND
21 JP1, JP2, JP4 3 2-pin header, male, TH SAM1035-02-ND place jumper on header
22 JP11 1 4-pin header, male, TH SAM1035-04-ND Place jumper on Pin 1 and 2
23 JP3 1 3-pin header, male, TH SAM1035-03-ND place jumper on pins 1-2
24
JP5, JP6, JP7,
JP8, JP9,
JP10
6 3-pin header, male, TH SAM1035-03-ND place jumpers on pins 2-3
25
Jumpers for
JP1, JP2, JP3,
JP4, JP5, JP6,
JP7, JP8, JP9,
JP10, JP11
11 Jumper 15-38-1024-ND
26 JTAG 1 14-pin connector, male, TH HRP14H-ND
27 LED 1 JP3QE SAM1032-03-ND DNP
28
LED1, LED2,
LED3
3 FARNELL: 852-9833 DNP
29 MSP430 2 MSP430FG6626IPZ
DNP: Free samples can be
ordered in the TI Store
30 Q2 1 Crystal
Q2: 4MHz
Buerklin: 78D134
31 Q3 1
MS3V-T1R (32.768kHz/
20ppm/12.5pF)
32 R1, R2, R4 3 0 Ohm, SMD0805 541-0.0ATR-ND
33 R10 1 100R, R0603 541-100GCT-ND
34 R11 1 1M, R0603 541-1.0MGCT-ND
35 R13, R15, R16 3 470R SMD0603 Buerklin: 07E564 DNP
www.ti.com Hardware
SLAU278AG – MAY 2009 – REVISED DECEMBER 2020
Submit Document Feedback
MSP430™ Hardware Tools 171
Copyright © 2020 Texas Instruments Incorporated
