Table B-5. MSP-TS430L092 Active Cable Bill of Materials
Pos. Ref Des No. Per Board Description Digi-Key Part No. Comment
1 C1, C3, C5, C6 4 100nF, SMD0603
2 C2, C4 2 1uF, SMD0805
3 R1, R10 2 10K, SMD0603
4 R2 1 4K7, SMD0603
5 R5, R6, R7, R9 4 100, SMD0603
6 R8 1 680k, SMD0603
7 R11, R15 2 1K, SMD0603
8 R12 0 SMD0603 DNP
9 R13 0 SMD0603 DNP
10 R14 1 0, SMD0603
11 IC1 1 SN74AUC1G04DBVR Manu: TI
12 IC2, IC3, IC4 3 SN74AUC2G125DCTR Manu: TI
13 J2 1 MICRO_STECKV_10
Reichelt: MicroMaTch-
Connector: MM FL 10G
14 JP1 1 2x2 Header JP2Q
Put jumper on Position 1 and 2.
Do not mix direction.
15 JP2 1 2-pin header, male, TH SAM1035-02-ND place jumper on header
16 JTAG 1 14-pin connector, male, TH HRP14H-ND
17 Q1 1
BC817-25LT1SMD, SOT23-
BEC
Digi-Key:
BC817-25LT1GOSCT-ND
18 U1, U2 2 TLVH431IDBVR SOT23-5 Manu: TI
Hardware www.ti.com
42 MSP430™ Hardware Tools SLAU278AG – MAY 2009 – REVISED DECEMBER 2020
Submit Document Feedback
Copyright © 2020 Texas Instruments Incorporated
