Texas Instruments MSP430 series User Manual

Table B-44. MSP-TS430PEU128 Bill of Materials
Pos. Ref Des
No. Per
Board
Description Digi-Key Part No. Comment
1 PCB 1
94x119.4mm, 4 layers MSP-TS430PEU128
Rev. 1.1
4 layers, green solder mask
2 D1 1 green LED, DIODE0805 516-1434-1-ND
3 JP1, JP2, JP4 3 2-pin header, male, TH SAM1035-02-ND Place jumper on header
4
JP5, JP6, JP7, JP8,
JP9, JP10
6
3-pin header, male, TH SAM1035-03-ND Place jumpers on pins 1-2 (SBW)
5 JP11, JP12, JP13 3 4-pin header, male, TH SAM1035-04-ND Place jumpers on pins 1-2 (AVCC=VCC)
6 JP3 1 4-pin header, male, TH SAM1035-04-ND Place jumpers on pins 1-2
7
JP1, JP2, JP3, JP4,
JP5, JP6, JP7, JP8,
JP9, JP10, JP11,
JP12, JP13
13
Jumper WM4592-ND
8 R1, R2, R4, R6, R8 5 0R, 0805 541-0.0ATR-ND
9 R10, R11 2 0R, 0805 541-0.0ATR-ND DNP
10 C3 1 2.2nF, CSMD0805 490-1628-2-ND DNP
11
C13, C14, C16, C17,
C18, C19, C29
7
4.7uF, 6.3V, CSMD0805 587-1302-2-ND
12 C11 1 10uF, 6.3V, CSMD0805 445-1372-2-ND
13 C12 1 10uF, 6.3V, CSMD0805 445-1372-2-ND DNP
14 C1, C2 2 12pF, CSMD0805 490-5531-2-ND DNP
15 R5 1 47K, 0805 311-47KARTR-ND
16
C4, C5, C6, C7, C8,
C15
6
100nF, CSMD0805 311-1245-2-ND
17 C9 1 100nF, CSMD0805 311-1245-2-ND DNP
18 R3, R7 2 330R, 0805 541-330ATR-ND
19 C10, C26 2 470nF, CSMD0805 587-1282-2-ND
20 BOOTST 1 10-pin connector, male, TH HRP10H-ND DNP, keep vias free of solder
21 JTAG 1 14-pin connector, male, TH HRP14H-ND
22 IC1 Socket 1 Socket: IC500-1284-009P Manuf. Yamaichi
23 IC1 2 MSP430F67791IPEU DNP: enclosed with kit. Is supplied by TI
24 J5 1 3-pin header, male, TH SAM1035-03-ND
25 Q1 1
Crystal: MS3V-T1R 32.768kHz
12.5pF ±20ppm
DNP: Crystal enclosed with kit. Keep vias free
of solder
26 TP1, TP2 2 Test point DNP, keep vias free of solder
27 J2,J4 2
26-pin header, TH SAM1029-26-ND DNP: Headers enclosed with kit. Keep vias free
of solder.
28 J2,J4 2
26-pin receptable, TH SAM1213-26-ND DNP: Receptacles enclosed with kit. Keep vias
free of solder.
29 J1, J3 2
38-pin header, TH SAM1029-38-ND DNP: Headers enclosed with kit. Keep vias free
of solder.
30 J1, J3 2
38-pin receptable, TH SAM1213-38-ND DNP: Receptacles enclosed with kit. Keep vias
free of solder.
31 Rubber feet 4 Rubber feet Buerklin: 20H1724 apply to bottom side corners
www.ti.com Hardware
SLAU278AG – MAY 2009 – REVISED DECEMBER 2020
Submit Document Feedback
MSP430™ Hardware Tools 175
Copyright © 2020 Texas Instruments Incorporated
