Table B-46. EM430F6137RF900 Bill of Materials
Pos. Ref Des
No. per
Board
Description Part No. Manufacturer
1 Q1 1
( CUSTOMER SUPPLY ) CRYSTAL, SMT, 4P,
26MHz
ASX-531(CS) AKER ELECTRONIC
2
C1-C5, C112,
C252, C381,
C391, C421,
C431, C451,
C522, C562
14
CAPACITOR, SMT, 0402, CER, 16V, 10%,
0.1uF
0402YC104KAT2A AVX
3 C101 1
CAPACITOR, SMT, 0603, CERAMIC, 0.47uF,
16V, 10%, X5R
0603YD474KAT2A AVX
4 R511 1 RES0402, 47.0K CRCW04024702F100 DALE
5 CON11 1
HEADER, THU, MALE, 14P, 2X7,
25.4x9.2x9.45mm, 90deg
09 18 514 6323 HARTING
7 D1 1 LED, SMT, 0603, GREEN, 2.1V APT1608MGC KINGBRIGHT
8 D2 1 LED, SMT, 0603, RED, 2.0V APT1608EC KINGBRIGHT
10 CON12 1 HEADER, THU, MALE, 3P, 1x3, 9.9x4.9x5.9mm 22-03-5035 MOLEX
11 C361, C371 2 50V, ±5%, 27pF GRM36COG270J50 MURATA
12 L451 1 FERRITE, SMT, 0402, 1.0kΩ, 250mA BLM15HG102SN1D MURATA
13 C403 1
CAPACITOR, SMT, 0402, CERAMIC, 100pF,
50V, ±0.25pF, C0G(NP0)
GRM1555C1H101JZ01 MURATA
14 L414 1
INDUCTOR, SMT, 0402, 2.2nH, ±0.2nH,
1000mA, 250MHz
LQW15AN2N2C10 MURATA
15 L413, L415 2
INDUCTOR, SMT, 0402, 15nH, ±5%, 460mA,
250MHz
LQW15AN15NJ00 MURATA
16 L402, L412 2
INDUCTOR, SMT, 0402, 18nH, ±5%, 370mA,
250MHz
LQW15AN18NJ00 MURATA
17 C401 1
CAPACITOR, SMT, 0402, CER, 1pF, 50V,
±0.25pF, NP0
GJM1555C1H1R0CB01D MURATA
18 C413 1
CAPACITOR, SMT, 0402, CERAMIC, 8.2pF,
50V, ±0.25pF, C0G(NP0)
GRM1555C1H8R2CZ01 MURATA
19
C402, C411-
C412, C414
4
CAPACITOR, SMT, 0402, CERAMIC, 1.5pF,
50V, ±0.25pF, C0G(NP0)
GRM1555C1H1R5CZ01 MURATA
20 L401, L411 2
INDUCTOR, SMT, 0402, 12nH, ±5%, 500mA,
250MHz
LQW15AN12NJ00 MURATA
21
C46-C48, C392,
C422
5
CAPACITOR, SMT, 0402, CERAMIC, 2.0pF,
50V, ±0.25pF, C0G(NP0)
GRM1555C1H2R0CZ01 Murata
22 L1 1
INDUCTOR, SMT, 0402, 6.2nH, ±0.1nH, 700mA,
250MHz
LQW15AN6N2D00 Murata
23 S1-S2 2
ULTRA-SMALL TACTILE SWITCH, SMT, 2P,
SPST-NO, 1.2x3x2.5mm, 0.05A, 12V
B3U-1000P OMRON
24 R7 1
RESISTOR/JUMPER, SMT, 0402, 0 Ω, 5%,
1/16W
ERJ-2GE0R00X (UN) PANASONIC
25 R2-R3, R6 3
RESISTOR, SMT, 0402, THICK FILM, 5%,
1/16W, 330
ERJ-2GEJ331 PANASONIC
27 C511 1
CAPACITOR, SMT, 0402, CER, 2200pF, 50V,
10%, X7R
ECJ-0EB1H222K PANASONIC
28
C111, C251,
C521, C561
4
CAPACITOR, SMT, 0603, CERAMIC, 10uF,
6.3V, 20%, X5R
ECJ-1VB0J106M PANASONIC
28a C041 1 CAP CERAMIC 4.7UF 6.3V X5R 0603 ECJ-1VB0J475M PANASONIC
29 R441 1 RESISTOR, SMT, THICK FILM, 56K, 1/16W, 1% ERJ-2RKF5602 PANASONIC
30 R1 1
RESISTOR/JUMPER, SMT, 0402, 0 Ω, 5%,
1/16W
ERJ-2GE0R00X PANASONIC
31 X1 1 SMA STRIGHT JACK, SMT 32K10A-40ML5 ROSENBERGER
