Table B-41. MSP-TS430PZ5x100 Bill of Materials
Pos. Ref Des
No. Per
Board
Description Digi-Key Part No. Comment
1 C1, C2 0 12pF, SMD0805 DNP
1b C3, C4 47pF, SMD0805
DNP: Only recommendation.
Check your crystal spec.
2 C6, C7 2 10uF, 10V, Tantal Size B 511-1463-2-ND
3
C5, C10, C11,
C12, C13, C14
4 100nF, SMD0805 311-1245-2-ND DNP: C12, C14
4 C8 0 2.2nF, SMD0805 DNP
5 C9 1 470nF, SMD0805 478-1403-2-ND
6 D1 1 green LED, SMD0805 67-1553-1-ND
7 J1, J2, J3, J4 0 25-pin header, TH
DNP: headers and receptacles
enclosed with kit. Keep vias
free of solder.
SAM1029-25-ND : Header
SAM1213-25-ND : Receptacle
8 J5 1 3-pin header, male, TH SAM1035-03-ND
9
JP5, JP6, JP7,
JP8, JP9,
JP10
6 3-pin header, male, TH SAM1035-03-ND Place jumpers on pins 2-3
10 JP1, JP2 2 2-pin header, male, TH SAM1035-02-ND Place jumper on header
11 JP3 1 3-pin header, male, TH SAM1035-03-ND Place jumper on pins 1-2
12 9 Jumper 15-38-1024-ND
Place on JP1, JP2, JP3, JP5,
JP6, JP7, JP8, JP9, JP10
13 JTAG 1 14-pin connector, male, TH HRP14H-ND
14 BOOTST 0 10-pin connector, male, TH DNP: Keep vias free of solder
15 Q1, Q2 0 Crystal
Q1: Micro Crystal MS1V-T1K
32.768kHz, C(Load) = 12.5pF
DNP: Keep vias free of solder
16 R3, R7 2 330 Ω, SMD0805 541-330ATR-ND
17
R1, R2, R4,
R6, R8, R9,
R10, R11, R12
3 0 Ω, SMD0805 541-000ATR-ND
DNP: R6, R8, R9, R10, R11,
R12
18 R5 1 47k Ω, SMD0805 541-47000ATR-ND
19 U1 1 Socket: IC357-1004-53N Manuf.: Yamaichi
20 PCB 1 90 x 82 mm 2 layers
21
Rubber
standoff
4 Select appropriate Apply to corners at bottom side
22 MSP430 2 MSP430F5438IPZ
DNP: Enclosed with kit supplied
by TI
Hardware www.ti.com
162 MSP430™ Hardware Tools SLAU278AG – MAY 2009 – REVISED DECEMBER 2020
Submit Document Feedback
Copyright © 2020 Texas Instruments Incorporated
