Table B-24. MSP-TS430PM64A Bill of Materials
Pos. Ref Des No. per Board Description Digi-Key Part No. Comment
1 C1, C2, 0 12pF, SMD0805 DNP
2 C3 0 2.2nF, SMD0805 DNP
3 C6, 1 10uF, 10V, Tantal Size B 511-1463-2-ND
4 C4, C5 2 100nF, SMD0805 478-3351-2-ND
5 D1 1 green LED, SMD0805 P516TR-ND
6 J1, J2, J3, J4 0 16-pin header, TH
DNP: Headers and receptacles
enclosed with kit. Keep vias
free of solder.
SAM1029-16-ND : Header
SAM1213-16-ND : Receptacle
7
J5, JP3, JP4,
JP5, JP6, JP7,
JP8, JP9
8 3-pin header, male, TH SAM1035-03-ND
8 JP1, JP2 2 2-pin header, male, TH SAM1035-02-ND Place jumper on header
9 2 Jumper 15-38-1024-ND Place on: J6, J7
10 JTAG 1 14-pin connector, male, TH HRP14H-ND
11 BOOTST 0 10-pin connector, male, TH DNP: Keep vias free of solder
12 Q1 0 Crystal
Micro Crystal MS1V-T1K
32.768kHz, C(Load) = 12.5pF
DNP: Keep vias free of solder
13 R3, R6 2 330 Ω, SMD0805 541-330ATR-ND
14
R1, R2, R5,
R7, R9, R10,
R11, R13, R14
2 0 Ω, SMD0805 541-000ATR-ND
DNP: R5, R7, R9, R10, R11,
R13, R14
15 R4 1 47k Ω, SMD0805 541-47000ATR-ND
16 U1 1 Socket: IC51-0644-807 Manuf.: Yamaichi
17 PCB 1 78 x 75 mm 4 layers
18
Rubber stand
off
4 select appropriate Apply to corners at bottom side
19 MSP430 2 MSP430F4152IPM
DNP: Enclosed with kit supplied
by TI
www.ti.com Hardware
SLAU278AG – MAY 2009 – REVISED DECEMBER 2020
Submit Document Feedback
MSP430™ Hardware Tools 103
Copyright © 2020 Texas Instruments Incorporated
