1.1 Kit Contents, MSP-TS430xx
• One READ ME FIRST document
• One 32.768-kHz crystal from Micro Crystal (except MSP-TS430PW24)
• One target socket module
• A 2×7-pin male JTAG connector is also present on the PCB (see different setup for L092)
• MSP430 MCU samples (see Table 1-1 for sample type)
Table 1-1. Individual Kit Contents, MSP-TS430xx
Part Number Socket Type Supported Devices Included Devices Headers and Comment
MSP-TS430D8
(green PCB)
8-pin D
(TSSOP ZIF)
MSP430G2210, MSP430G2230
1 x MSP430G2210ID and
1 x MSP430G2230ID
Two PCB 1×4-pin headers
(two male and two female)
MSP-TS430PW14
(green PCB)
14-pin PW
(TSSOP ZIF)
MSP430F20xx, MSP430G2x01,
MSP430G2x11, MSP430G2x21,
MSP430G2x31
2 × MSP430F2013IPW
Four PCB 1×7-pin headers
(two male and two female)
MSP-TS430L092
(green PCB)
14-pin PW
(TSSOP ZIF)
MSP430L092 2 × MSP430L092IPW
Four PCB 1×7-pin headers
(two male and two female)
A "Micro-MaTch" 10-pin female
connector is also present on the PCB
which connects the kit with an 'Active
Cable' PCB. This 'Active Cable' PCB
is connected by 14-pin JTAG cable
with the FET430UIF.
MSP-TS430PW20
(green PCB)
20-pin PW
(TSSOP ZIF)
MSP430FR2311IPW20,
MSP430FR2311IPW16
None. Free samples can be
ordered in the TI Store.
Four PCB 1×12-pin headers
(two male and two female)
MSP-TS430RHL20
(green PCB)
20-pin RHL
(VQFN ZIF)
MSP430FR2522IRHL,
MSP430FR2422IRHL
None. Free samples can be
ordered in the TI Store.
Four PCB 1×10-pin headers
(two male and two female)
MSP-TS430PW24
(green PCB)
24-pin PW
(TSSOP ZIF)
MSP430AFE2xx 2 × MSP430AFE253IPW
Four PCB 1×12-pin headers
(two male and two female)
MSP-TS430RGE24A
(red PCB)
24-pin RGE
(QFN ZIF)
MSP430FR2433IRGE
None. Free samples can be
ordered in the TI Store.
Four PCB 1×6-pin headers
(two male and two female)
MSP-TS430DW28
(green PCB)
28-pin DW
(SSOP ZIF)
MSP430F11x1, MSP430F11x2,
MSP430F12x, MSP430F12x2,
MSP430F21xx
Supports devices in 20- and 28-pin DA
packages
2 × MSP430F123IDW
Four PCB 1×12-pin headers
(two male and two female)
MSP-TS430PW28
(green PCB)
28-pin PW
(TSSOP ZIF)
MSP430F11x1, MSP430F11x2,
MSP430F12x, MSP430F12x2,
MSP430F21xx
2 × MSP430F2132IPW
Four PCB 1×12-pin headers
(two male and two female)
MSP-TS430PW28A
(red PCB)
28-pin PW
(TSSOP ZIF)
MSP430F20xx, MSP430G2xxx in 14-, 20-,
and 28-pin PW packages, MSP430TCH5E
in PW package
2 × MSP430G2452IPW20
Four PCB 1×12-pin headers
(two male and two female)
MSP-TS430RHB32A
(red PCB)
32-pin RHB
(QFN ZIF)
MSP430i204x 2 × MSP430i2041TRHB
Eight PCB 1×8-pin headers
(four male and four female)
MSP-TS430DA38
(green PCB)
38-pin DA
(TSSOP ZIF)
MSP430F22xx, MSP430G2x44,
MSP430G2x55
2 × MSP430F2274IDA
2 × MSP430G2744IDA
2 × MSP430G2955IDA
Four PCB 1×19-pin headers
(two male and two female)
MSP-TS430QFN23x0
(green PCB)
40-pin RHA
(QFN ZIF)
MSP430F23x0 2 × MSP430F2370IRHA
Eight PCB 1×10-pin headers
(four male and four female)
MSP-TS430RSB40
(green PCB)
40-pin RSB
(QFN ZIF)
MSP430F51x1, MSP430F51x2 2 × MSP430F5172IRSB
Eight PCB 1×10-pin headers
(four male and four female)
MSP-TS430RHA40A
(red PCB)
40-pin RHA
(QFN ZIF)
MSP430FR572x, MSP430FR573x 2 × MSP430FR5739IRHA
Eight PCB 1×10-pin headers
(four male and four female)
MSP-TS430DL48
(green PCB)
48-pin DL
(TSSOP ZIF)
MSP430F42x0 2 × MSP430F4270IDL
Four PCB 2×12-pin headers
(two male and two female)
MSP-TS430PT48
(green PCB)
48-pin PT
(QFP ZIF)
MSP430FR235x
None. Free samples can be
ordered in the TI Store.
Eight PCB 1×12-pin headers
(four male and four female)
MSP-TS430PT48A
(red PCB)
48-pin PT
(QFP ZIF)
MSP430FR247x
None. Free samples can be
ordered in the TI Store.
Eight PCB 1×12-pin headers
(four male and four female)
MSP-TS430RGZ48B
(blue PCB)
48-pin RGZ
(QFN ZIF)
MSP430F534x 2 × MSP430F5342IRGZ
Eight PCB 1×12-pin headers
(four male and four female)
MSP-TS430RGZ48C
(black PCB)
48-pin RGZ
(QFN ZIF)
MSP430FR58xx and MSP430FR59xx 2 × MSP430FR5969IRGZ
Eight PCB 1×12-pin headers
(four male and four female)
Get Started Now! www.ti.com
12 MSP430™ Hardware Tools SLAU278AG – MAY 2009 – REVISED DECEMBER 2020
Submit Document Feedback
Copyright © 2020 Texas Instruments Incorporated
