Table B-26. MSP-TS430PM64F Bill of Materials (BOM)
Pos. Ref Des
Number
per
Board
Description DigiKey Part Number Comment
1 PCB 1 90.0 x 92.5 mm MSP-TS430PM64F Rev. 1.0 2 layers, purple solder mask
2
JP1, JP2, JP9, JP13,
JP14, JP15,
6 2-pin header, male, TH SAM1035-02-ND place jumper on header
3 JP17, JP18 2 2-pin header, male, TH SAM1035-02-ND place jumper on header's pin1 only
4 JP10, JP11 2 2-pin header, male, TH SAM1035-02-ND DNP, keep pads free of solder
5 J1 1 3-pin header, male, TH SAM1035-03-ND place jumpers on pins 1-2
6
JP3, JP4, JP5, JP6,
JP7, JP8, JP16
7 3-pin header, male, TH SAM1035-03-ND place jumpers on pins 2-3
7 J2 1 3-pin header, male, TH SAM1035-03-ND
8 R2, R5, R6, R8, R9 5 0R, 0805 541-0.0ATR-ND DNP
9 R3, R12, R13 3 0R, 0805 541-0.0ATR-ND
10 C5 1 1.1nF, CSMD0805 490-1623-2-ND
11 C3, C7 2 1uF/10V, CSMD0805 490-1702-2-ND
12 C15 1 4u7, CSMD0805 445-1370-1-ND DNP
13 R7, R15 1 10k, 0805 541-10KATR-ND
14 R4 1 47k, 0805 541-47KATR-ND
15 C4, C6, C10, C11 4 100nF, CSMD0805 490-1666-1-ND
16 R1 1 330R, 0805 541-330ATR-ND
17 R10, R11 2 330R, 0805 541-330ATR-ND DNP
18 R14 1 47k, 0805 541-47KATR-ND DNP
19 C1, C2, C8, C9 4 DNP, CSMD0805 DNP
20 SW2 1 EVQ-11L05R P8079STB-ND DNP, Lacon: 1251459
21 SW1 1 EVQ-11L05R P8079STB-ND DNP, Lacon: 1251459
22 J3, J4, J5, J6 4 16-pin header, TH SAM1029-16-ND
DNP: headers enclosed with kit.
Keep vias free of solder.
23 J3, J4, J5, J6 4 16-pin receptacle, TH SAM1213-16-ND
DNP: receptacles enclosed with kit.
Keep vias free of solder.
24 TP1, TP2 2 Testpoint DNP, keep pads free of solder
25 BSL 1 10-pin connector, male, TH HRP10H-ND
26 JTAG 1 14-pin connector, male, TH HRP14H-ND
27 U1 1 Socket:IC51-0644-807 Manuf. Yamaichi
28 U1 2 MSP430FR6972IPMR
DNP: enclosed with kit.
Is supplied by TI.
29 Q1 1
DNP: MS3V-TR1
(32,768kHz/ 20ppm/12,5pF)
depends on application
Micro Crystal, DNP, enclosed in kit,
keep vias free of solder
30 Q2 1 DNP, Crystal depends on application DNP, keep vias free of solder
31 D1 1
green LED, HSMG-C170
DIODE0805
516-1434-1-ND Avago, Farnell 5790852
32 D3 1 red (DNP), DIODE0805 DNP
33 D2 1 yellow (DNP), DIODE0805 DNP
34 Rubber stand off 4 Buerklin: 20H1724 apply to corners at bottom side
www.ti.com Hardware
SLAU278AG – MAY 2009 – REVISED DECEMBER 2020
Submit Document Feedback
MSP430™ Hardware Tools 109
Copyright © 2020 Texas Instruments Incorporated
