1.12 Kit Contents, FET430F6137RF900
One READ ME FIRST document
One legal notice
One MSP-FET430UIF interface module
Two EM430F6137RF900 target socket modules. This is the PCB on which is soldered a CC430F6137 device
in a 64-pin RGC package. A 2×7-pin male connector is also present on the PCB.
Two CC430EM battery packs
Four AAA batteries
Two 868-MHz or 915-MHz antennas
Two 32.768-kHz crystals
18 PCB 2x4-pin headers
One USB cable
One 14-pin JTAG conductor cable
1.13 Kit Contents, EM430Fx1x7RF900
One READ ME FIRST document
One legal notice
Two target socket module
MSP-EM430F5137RF900: Two EM430F5137RF900 target socket modules. This is the PCB on which is
soldered a CC430F5137 device in a 48-pin RGZ package. A 2×7-pin male connector is also present on the
PCB
MSP-EM430F6137RF900: Two EM430F6137RF900 target socket modules. This is the PCB on which is
soldered a CC430F6137 device in a 64-pin RGC package. A 2×7-pin male connector is also present on the
PCB
MSP-EM430F6147RF900: Two EM430F6147RF900 target socket modules. This is the PCB on which is
soldered a CC430F6147 device in a 64-pin RGC package. A 2×7-pin male connector is also present on the
PCB
Two CC430EM battery packs
Four AAA batteries
Two 868- or 915-MHz antennas
Two 32.768-kHz crystals
18 PCB 2×4-pin headers
1.14 Hardware Installation, MSP-FET and MSP-FET430UIF
See the MSP Debuggers User’s Guide.
