Table B-33. MSP-TS430PN80C Bill of Materials
Designator Quantity Value Description Package Reference Part Number Manufacturer Comments
!PCB 1 Printed Circuit Board MCU022 Any
BSL 1
Header(Shrouded),
2.54mm, 5x2, Gold, TH
Header, 2.54mm, 5x2,
TH
AWHW-10G-0202-T Assman WSW
C3, C7 2 1uF
CAP, CERM, 1 uF, 10
V, ±10%, X5R, 0805
0805 GRM216R61A105KA01D MuRata
C4, C6, C11 3 0.1uF
CAP, CERM, 0.1 µF,
50 V, ±10%, X7R,
0805
0805 GRM21BR71H104KA01L MuRata
C5 1 1100pF
CAP, CERM, 1100 pF,
50 V, ±5%, C0G/NP0,
0805
0805 GRM2165C1H112JA01D MuRata
C13 1 1000pF
CAP, CERM, 1000 pF,
50 V, ±5%, C0G/NP0,
AEC-Q200 Grade 1,
0805
0805 GCM2165C1H102JA16D MuRata
C14, C15 2 27pF
CAP, CERM, 27 pF, 50
V, ±5%, C0G/NP0,
0603
0603 GRM1885C1H270JA01D MuRata
C16 1 47uF
CAP, CERM, 47 µF,
6.3 V, ±20%, X5R,
0805
0805 GRM21BR60J476ME15L MuRata
D1 1 Green LED, Green, SMD LED_0805 APT2012LZGCK Kingbright
D2 1 Blue LED, Blue, SMD LED_0805 150080BS75000 Wurth Elektronik
H1, H2, H3,
H4
4
Bumpon, Cylindrical,
0.312 X 0.200, Black
Black Bumpon SJ61A1 3M
IC1 1
Socket, QFP-80,
0.5 mm Pitch
Socket, QFN-80,
0.5 mm Pitch
IC357-0804-096P-1 Yamaichi Electronics
J1, J2, JP5,
JP6, JP7,
JP8, JP9,
JP10
8
Header, 100mil, 3x1,
Gold, TH
3x1 Header TSW-103-07-G-S Samtec
J3, J4, J5, J6 4
Header, 100mil, 20x1,
Gold, TH
20x1 Header TSW-120-07-G-S Samtec
Not installed,
included in kit
J3A, J4A,
J5A, J6A
4
Receptacle, 2.54 mm,
20x1, Gold, TH
Receptacle, 2.54mm,
20x1, TH
PPPC201LFBN-RC
Sullins Connector
Solutions
Not installed,
included in kit
JP1, JP2,
JP3, JP4,
JP11, JP12,
JP13, JP14
8
Header, 100mil, 2x1,
Gold, TH
2x1 Header TSW-102-07-G-S Samtec
JTAG 1
Header (shrouded),
100 mil, 7x2, Gold, TH
7x2 Shrouded Header SBH11-PBPC-D07-ST-BK
Sullins Connector
Solutions
Q1 1
Crystal, 32.768 kHz,
12.5pF, SMD
1.4x1.4x5.0mm SMD
MS3V-T1R 32.768KHZ
±20PPM 12.5PF
Micro Crystal AG
Not installed,
included in kit
Q3 1 Crystal, 8MHz, SMD 4.7x4.1mm
R- 8,00M-ZTACS/
MT-0,5-0,4-H-30/30-TR
Auris-GmbH
R1 1 330
RES, 330, 5%,
0.125 W, 0805
0805 CRCW0805330RJNEA Vishay-Dale
R2 1 200
RES, 200, 5%,
0.125 W, 0805
0805 CRCW0805200RJNEA Vishay-Dale
R3, R10,
R11, R12,
R18, R19,
R20, R21
8 0
RES, 0, 5%, 0.125 W,
0805
0805 CRCW08050000Z0EA Vishay-Dale
R7 1 47k
RES, 47 k, 5%,
0.125 W, 0805
0805 CRCW080547K0JNEA Vishay-Dale
R16, R17 2 4.7k
RES, 4.7 k, 5%,
0.125 W, 0805
0805 CRCW08054K70JNEA Vishay-Dale
R22 1 22
RES, 22, 5%, 0.1 W,
0603
0603 CRCW060322R0JNEA Vishay-Dale
www.ti.com Hardware
SLAU278AG – MAY 2009 – REVISED DECEMBER 2020
Submit Document Feedback
MSP430™ Hardware Tools 133
Copyright © 2020 Texas Instruments Incorporated
