Table B-30. MSP-TS430PN80 Bill of Materials
Pos. Ref Des No. per Board Description Digi-Key Part No. Comment
1 C1, C2 0 12pF, SMD0805 DNP: C1, C2
1.1 C3, C4 0 47pF, SMD0805
DNP: Only recommendation.
Check your crystal spec.
2 C6, C7 1 10uF, 10V, Tantal Size B 511-1463-2-ND
3 C5 1 100nF, SMD0805 478-3351-2-ND
4 C8 1 10nF, SMD0805 478-1383-2-ND
5 D1 1 green LED, SMD0603 475-1056-2-ND
6 J1, J2, J3, J4 0 25-pin header, TH
DNP: Headers and receptacles
enclosed with kit.Keep vias free
of solder.
SAM1029-20-ND : Header
SAM1213-20-ND : Receptacle
7 J5, JP1 2 3-pin header, male, TH SAM1035-03-ND
8 J6, JP2 2 2-pin header, male, TH SAM1035-02-ND Place jumper on header
9 3 Jumper 15-38-1024-ND Place on: J6, JP2, JP1/Pos1-2
10 JTAG 1 14-pin connector, male, TH HRP14H-ND
11 BOOTST 0 10-pin connector, male, TH DNP: Keep vias free of solder
12 Q1, Q2 0 Crystal
Q1: Micro Crystal MS1V-T1K
32.768kHz, C(Load) = 12.5pF
DNP: Keep vias free of solder
13 R3 1 560 Ω, SMD0805 541-560ATR-ND
14
R1, R2, R4,
R6, R7, R10,
R11, R12
2 0 Ω, SMD0805 541-000ATR-ND
DNP: R4, R6, R7, R10, R11,
R12
15 R5 1 47k Ω, SMD0805 541-47000ATR-ND
16 U1 1 Socket: IC201-0804-014 Manuf.: Yamaichi
17 PCB 1 77 x 77 mm 2 layers
18
Adhesive
Plastic feet
4 ~6mm width, 2mm height
for example, 3M Bumpons Part
No. SJ-5302
Apply to corners at bottom side
19 MSP430 2 MSP430FG439IPN
DNP: Enclosed with kit supplied
by TI
Hardware www.ti.com
124 MSP430™ Hardware Tools SLAU278AG – MAY 2009 – REVISED DECEMBER 2020
Submit Document Feedback
Copyright © 2020 Texas Instruments Incorporated
