Jumper J4
Open to disconnect LED
Orient Pin 1 of
MSP430 device
Jumper J5
Open to measure current
Connector J3
External power connector
Remove R8 and jumper R9
D1
LED connected to P1.0
Connector JTAG
For JTAG Tool
Connector BOOTST
For Bootloader Tool
Figure B-19. MSP-TS430DW28 Target Socket Module, PCB
Hardware
www.ti.com
58 MSP430™ Hardware Tools SLAU278AG – MAY 2009 – REVISED DECEMBER 2020
