Table B-39. MSP-TS430PZ100D Bill of Materials
Pos. Ref Des
Number
Per
Board
Description Digi-Key Part No. Comment
1 PCB 1 90.0 x 100.0 mm MSP-TS430PZ100D
Rev 1.2
2 layers, white solder mask
2 JP1, JP2,
JP9
3 2-pin header, male, TH SAM1035-02-ND place jumper on header
3 JP10, JP11,
JP12
3 2-pin header, male, TH SAM1035-02-ND DNP, keep pads free of solder
4 J1 1 3-pin header, male, TH SAM1035-03-ND place jumpers on pins 1-2
5 JP3, JP4,
JP5, JP6,
JP7, JP8
6 3-pin header, male, TH SAM1035-03-ND place jumpers on pins 2-3
6 J2 1 3-pin header, male, TH SAM1035-03-ND
7 R2, R3, R5,
R6, R8, R9
6 0R, 0805 541-0.0ATR-ND DNP
8 R7, R12,
R13
3 0R, 0805 541-0.0ATR-ND
9 C5 1 1.1nF, CSMD0805 490-1623-2-ND
10 C3, C7 2 1uF/10V, CSMD0805 490-1702-2-ND
11 C12 1 1uF/10V, CSMD0805 490-1702-2-ND DNP
12 R4 1 47k, 0805 541-47KATR-ND
13 C4, C6, C10,
C11
4 100nF, CSMD0805 490-1666-1-ND
14 C13 1 100nF, CSMD0805 490-1666-1-ND DNP
15 C15 1 4u7, CSMD0805 445-1370-1-ND DNP
16 R1 1 330R, 0805 541-330ATR-ND
17 C14 1 470nF, CSMD0805 587-1290-2-ND DNP
18 R10, R11 2 330R, 0805 541-330ATR-ND DNP
19 R14 1 47k, 0805 541-47KATR-ND DNP
20 C1, C2, C8,
C9
4 DNP, CSMD0805 DNP
21 SW2 1 EVQ-11L05R P8079STB-ND DNP
22 SW1 1 EVQ-11L05R P8079STB-ND DNP
23 J3, J4, J5, J6 4 25-pin header, TH
SAM1029-25-ND
DNP: headers and receptacles enclosed
with kit. Keep vias free of solder.
: Header
24 J3, J4, J5, J6 4 25-pin receptacle, TH
SAM1213-25-ND
DNP: headers and receptacles enclosed
with kit. Keep vias free of solder.
: Receptacle
25 TP1, TP2 2 Testpoint DNP, keep pads free of solder
26 BSL 1 10-pin connector, male, TH HRP10H-ND DNP, keep vias free of solder
27 JTAG 1 14-pin connector, male, TH HRP14H-ND
28 IC1 1 Socket: IC201-1004-008 Manuf. Yamaichi
29 IC1 1 MSP430FR6989 DNP: enclosed with kit. Is supplied by TI
30 Q1 1 DNP: MS3V-TR1 (32768kHz/
20ppm/12,5pF)
depends on application Micro Crystal, DNP, enclosed in kit, keep
vias free of solder
31 Q2 1 DNP, Crystal depends on application DNP, keep vias free of solder
32 D1 1 green LED, DIODE0805 P516TR-ND
33 D3 1 red (DNP), DIODE0805 DNP
34 D2 1 yellow (DNP), DIODE0805 DNP
Hardware www.ti.com
154 MSP430™ Hardware Tools SLAU278AG – MAY 2009 – REVISED DECEMBER 2020
