Table B-40. MSP-TS430PZ100E Bill of Materials
Item No. Designator Quantity Description Supplier Part Number Note
1 PCB1 1 PCB, 3.20" x 4.50"
2 layers, yellow solder
mask
2 BSL 1
Header(Shrouded), 2.54mm, 5x2,
Gold, TH
AWHW-10G-0202-T-ND
3 C1, C2 2
CAP, CERM, 12 pF, 50 V, ±5%, C0G/
NP0, 0805
311-1100-1-ND DNP
4 C3, C7 2
CAP, CERM, 1 µF, 10 V, ±10%, X5R,
0805
490-1702-1-ND
5 C4, C6, C10, C11 4
CAP, CERM, 0.1 µF, 50 V, ±10%,
X7R, 0805
490-1666-1-ND
6 C5 1
CAP, CERM, 1100 pF, 50 V, ±5%,
C0G/NP0, 0805
490-1623-1-ND
7 C8, C9 2
CAP, CERM, 22 pF, 50 V, ±5%, C0G/
NP0, 0805
490-3608-1-ND DNP
8 C12 1
CAP, CERM, 4.7 µF, 10 V, +80/-20%,
Y5V, 0805
311-1371-2-ND DNP
9 C13 1
CAP, CERM, 1000 pF, 50 V, ±5%,
C0G/NP0, AEC-Q200 Grade 1, 0805
490-8032-1-ND
10 C14, C15 2
CAP, CERM, 27 pF, 50 V, ±5%, C0G/
NP0, 0603
490-1413-1-ND
11 C16 1
CAP, CERM, 47 µF, 6.3 V, ±20%,
X5R, 0805
490-9960-1-ND
12 D1 1 LED, Green, SMD 754-1939-1-ND
13 D2 1 LED, Blue, SMD 732-4982-1-ND
14 H1, H2, H3, H4 4 125mil Mounting Hole
15 H5, H6, H7, H8 4
Bumpon, Cylindrical, 0.312 X 0.200,
Black
SJ5746-0-ND
16 IC1 1 Socket, QFP-100, 0.5 mm Pitch
17
J1, J2, JP5, JP6, JP7,
JP8, JP9, JP10
8 Header, 100mil, 3x1, Gold, TH SAM1029-03-ND
18 J3, J4, J5, J6 4 Header, 100mil, 25x1, Gold, TH SAM1029-25-ND
DNP: Headers are
enclosed in kit. Keep
vias free of solder
19 J3, J4, J5, J6 4 Receptacle, 100mil, 25x1, Gold, TH SAM1213-25-ND
DNP: Receptacles are
enclosed in kit. Keep
vias free of solder
20
JP1, JP2, JP3, JP4,
JP11, JP12, JP13, JP14
8 Header, 100mil, 2x1, Gold, TH SAM1029-02-ND
21 JTAG 1
Header (shrouded), 100 mil, 7x2,
Gold, TH
S9170-ND
22 Q1, Q2 2 32.768kHz ±20ppm 12.5pF 94M8466
DNP: Keep holes free of
solder
23 Q3 1 ZTACS Crystal Resonator 77D9806 DNP
24 R1 1 RES, 330, 5%, 0.125 W, 0805 541-330ACT-ND
25 R2 1 RES, 200, 5%, 0.125 W, 0805 541-200ACT-ND
26
R3, R10, R11, R12,
R18, R19, R20, R21
8 RES, 0, 5%, 0.125 W, 0805 541-0.0ACT-ND
27
R4, R5, R6, R8, R9,
R14, R15
7 RES, 0, 5%, 0.1 W, 0603 541-0.0GCT-ND DNP
28 R7 1 RES, 47 k, 5%, 0.125 W, 0805 541-47KACT-ND
29 R13 1 RES, 47 k, 5%, 0.125 W, 0805 541-47KACT-ND DNP
30 R16, R17 2 RES, 4.7 k, 5%, 0.125 W, 0805 541-4.7KACT-ND
Hardware www.ti.com
158 MSP430™ Hardware Tools SLAU278AG – MAY 2009 – REVISED DECEMBER 2020
