Table B-40. MSP-TS430PZ100E Bill of Materials (continued)
Item No. Designator Quantity Description Supplier Part Number Note
31 R22 1 RES, 22, 5%, 0.1 W, 0603 541-22GCT-ND
32
SH‑J1, SH‑JP1,
SH‑JP2, SH‑JP3,
SH‑JP4, SH‑JP5,
SH‑JP6, SH‑JP7,
SH‑JP8, SH‑JP9,
SH‑JP10, SH‑JP11,
SH‑JP12, SH‑JP13,
SH‑JP14
15 Shunt, 100mil, Gold plated, Black 3M9580-ND
J1: 1-2, JP1: 1-2, JP2:
1-2, JP3: 1-2, JP4: 1-2,
JP5: 2-3, JP6: 2-3, JP7:
2-3, JP8: 2-3, JP9: 2-3,
JP10: 2-3, JP11: 1-2,
JP12: 1-2, JP13: 1-2,
JP14: 1-2
33 SW1, SW2 2 Switch Tactile SPST-NO 0.02A 15V P8079STB-ND
34 SW3, SW4, SW5 3
Switch, DPST, Slide, Off-On, 1 Pos,
0.15A, 30V, TH
GH7727-ND
Install with arrow
matching arrow on
PCB. S5 should be
"ON", S3 and S4 should
be "OFF"
35
TP1, TP2, TP3, TP4,
TP5, TP6
6 Test Point, Miniature, Black, TH 36-5001-ND DNP
www.ti.com
Hardware
SLAU278AG – MAY 2009 – REVISED DECEMBER 2020
Submit Document Feedback
MSP430™ Hardware Tools 159
Copyright © 2020 Texas Instruments Incorporated
