Table B-13. MSP-TS430RHB32A Bill of Materials
Pos. Ref Des
No. per
Board
Description Digi-Key Part No. Comment
1 PCB 1 76.9 x 67.6 mm MSP‐TS430RHB32A Rev. 1 2 layers, red solder mask
2 D1 1 green LED, DIODE0805 P516TR‐ND
3 JP1, JP2 2 2‐pin header, male, TH SAM1035‐02‐ND place jumper on header
4 JP3, JP4,
JP5, JP6,
JP7, JP8, JP9
7 3‐pin header, male, TH SAM1035‐03‐ND place jumpers on pins 1‐2
(SBW)
5 R1, R4 2 0R, 0805 541‐0.0ATR‐ND
6 C8 1 2.2nF, CSMD0805 490‐1628‐2‐ND DNP
7 R6, R8, R9,
R10, R11,
R12, R13,
R14
8 10k, 0805 311‐10KARTR‐ND DNP
8 C12 1 10uF, CSMD0805 445‐1371‐2‐ND
9 R2 1 20k/0.1%, 0805 P20KDACT‐ND
10 R5 1 47K, 0805 311‐47KARTR‐ND
11 C13, C14 2 100nF, CSMD0805 311‐1245‐2‐ND
12 R3 1 330R, 0805 541‐330ATR‐ND
13 C9 1 470nF, CSMD0805 445‐1357‐2‐ND
14 J1, J2, J3, J4 1 8‐pin header, TH SAM1029‐08‐ND DNP: headers and
receptacles, enclosed with kit.
Keep vias free of solder.
15 J1, J2, J3, J4 1 8‐pin receptable, TH SAM1213‐08‐ND DNP: headers and
receptacles, enclosed with kit.
Keep vias free of solder.
16 JTAG 1 14‐pin connector, male, TH HRP14H‐ND
17 U1 1 Socket QFN11T032‐003 Manuf.: Yamaichi
18 U1 1 MSP430i2041TRHB DNP: enclosed with kit.
Is supplied by TI
19 J5 1 3‐pin header, male, TH SAM1035‐03‐ND
20 Rubber stand
off
4 Buerklin: 20H1724 apply to corners at bottom
side
Hardware www.ti.com
68 MSP430™ Hardware Tools SLAU278AG – MAY 2009 – REVISED DECEMBER 2020
Submit Document Feedback
Copyright © 2020 Texas Instruments Incorporated
