1.2 Kit Contents, MSP-FET430xx
• One READ ME FIRST document
• One MSP-FET430UIF USB interface module. This is the unit that has a USB B-connector on one end of the
case, and a 2×7-pin male connector on the other end of the case.
• One USB cable
• One 32.768-kHz crystal from Micro Crystal, if the board has an option to use the quartz.
• A 2×7-pin male JTAG connector is also present on the PCB (see different setup for L092)
• One 14-Pin JTAG conductor cable
• One small box containing two MSP430 device samples (See table for Sample Type)
• One target socket module. To determine the devices used for each board and a summary of the board, see
Table 1-1. The name of MSP-TS430xx board can be derived from the name of the MSP-FET430xx kit; for
example, the MSP-FET430U28A kit contains the MSP-TS430PW28A board.
See the device data sheets for device specifications. Device errata can be found in the respective device
product folder on the web provided as a PDF document. Depending on the device, errata may also be found in
the device bug database at www.ti.com/sc/cgi-bin/buglist.cgi.
1.3 Kit Contents, MSP-FET
• One READ ME FIRST document
• One MSP-FET interface module
• One USB cable
• One 14-conductor cable
1.4 Kit Contents, MSP-FET430UIF
• One READ ME FIRST document
• One MSP-FET430UIF interface module
• One USB cable
• One 14-conductor cable
1.5 Kit Contents, MSP-FET430PIF
• One READ ME FIRST document
• One MSP-FET430PIF interface module
• One 25-conductor cable
• One 14-conductor cable
Note
NOTE: This part is obsolete and is not recommended to use in new design.
1.6 Kit Contents, eZ430-F2013
• One QUICK START GUIDE document
• One eZ430-F2013 development tool including one MSP430F2013 target board
1.7 Kit Contents, eZ430-T2012
• Three MSP430F2012-based target boards
Get Started Now!
www.ti.com
14 MSP430™ Hardware Tools SLAU278AG – MAY 2009 – REVISED DECEMBER 2020
Submit Document Feedback
Copyright © 2020 Texas Instruments Incorporated
