Table B-8. MSP-TS430PW24 Bill of Materials
Position Ref Des
No. per
Board
Description Digi-Key Part No. Comment
1 C1, C2 0 12pF, SMD0805 DNP
2 C5 1 2.2nF, SMD0805
3 C3, C7 2 10uF, 10V, SMD0805
4 C4, C6, C8 3 100nF, SMD0805 478-3351-2-ND
5 D1 1 green LED, SMD0805 P516TR-ND
6 J1, J2 0 12-pin header, TH
SAM1029-07-ND
SAM1213-07-ND
DNP: Headers and receptacles enclosed
with kit. Keep vias free of solder.
(Header and Receptacle)
7
J5, JP1,
JP4, JP5,
JP6, JP7,
JP8, JP9
8 3-pin header, male, TH SAM1035-03-ND
Place jumper on 1-2 of JP4-JP9
Place on 1-2 on JP1
8 JP2, JP3 2 2-pin header, male, TH SAM1035-02-ND Place jumper on header
9 9 Jumper 15-38-1024-ND see Pos 7 and 8
10 JTAG 1
14-pin connector, male,
TH
HRP14H-ND
11 Q1 0 Crystal DNP: keep vias free of solder
12 R1, R7 2 330 Ω, SMD0805 541-330ATR-ND
13
R5, R6, R8,
R9,
2 0 Ohm, SMD0805 541-000ATR-ND DNP R5, R6
14 R4 1 47k Ohm, SMD0805 541-47000ATR-ND
15 U1 1
Socket: OTS
24(28)-065-02-00
Manuf.: Enplas
16 PCB 1 68.5 x 61 mm 2 layers
17
Adhesive
plastic feet
4
Approximately 6mm width,
2mm height
for example, 3M Bumpons
Part No. SJ-5302
Apply to corners at bottom side
18 MSP430 2 MSP430AFE2xx DNP: enclosed with kit, supplied by TI
www.ti.com Hardware
SLAU278AG – MAY 2009 – REVISED DECEMBER 2020
Submit Document Feedback
MSP430™ Hardware Tools 53
Copyright © 2020 Texas Instruments Incorporated
