Texas Instruments MSP430 series User Manual

Table B-19. MSP-TS430PT48 Bill of Materials
Ref Des
No. per
Board
Value Description
Package
Reference
Part Number Manufacturer
!PCB 1 Printed circuit board MCU061 Any
BSL 1
Header(Shrouded),
2.54mm, 5x2, Gold, TH
Header, 2.54mm,
5x2, TH
AWHW-10G-0202-T Assman WSW
C5 1 1100pF
CAP, CERM, 1100 pF, 50
V, +/- 5%, C0G/NP0, 0805
0805 GRM2165C1H112JA01D MuRata
C6 1 0.1uF
CAP, CERM, 0.1 µF, 50 V,
+/- 10%, X7R, 0805
0805 GRM21BR71H104KA01L MuRata
C7 1 10uF
CAP, CERM, 10 µF, 16 V,
+/- 10%, X5R, 0805
0805 0805YD106KAT2A AVX
D1 1 Green LED, Green, SMD LED_0805 APT2012LZGCK Kingbright
D2 1 Blue LED, Blue, SMD LED_0805 150080BS75000 Wurth Elektronik
H5, H6, H7,
H8
4
Bumpon, Cylindrical,
0.312 X 0.200, Black
Black Bumpon SJ61A1 3M
IC1 1
Socket, QFP-48, 0.5 mm
Pitch
Socket, QFP-48,
0.5 mm Pitch
IC357-0484-142P-2
Yamaichi
Electronics
J1, J2, JP5,
JP6, JP7,
JP8, JP9,
JP10
8
Header, 100mil, 3x1, Gold,
TH
3x1 Header TSW-103-07-G-S Samtec
J3, J4, J5,
J6
4
Header, 100mil, 12x1,
Gold, TH
12x1 Header TSW-112-07-G-S Samtec
J3A, J4A,
J5A, J6A
4
Receptacle, 2.54mm,
12x1, Gold, TH
Receptacle,
2.54mm, 12x1, TH
PPPC121LFBN-RC
Sullins Connector
Solutions
JP1, JP11,
JP12
3
Header, 100mil, 2x1, Gold,
TH
2x1 Header TSW-102-07-G-S Samtec
JTAG 1
Header (shrouded), 100
mil, 7x2, Gold, TH
7x2 Shrouded
Header
SBH11-PBPC-D07-ST-BK
Sullins Connector
Solutions
R1 1 330
RES, 330, 5%, 0.125 W,
0805
0805 CRCW0805330RJNEA Vishay-Dale
R2 1 200
RES, 200, 5%, 0.125 W,
0805
0805 CRCW0805200RJNEA Vishay-Dale
R3, R10,
R19, R20,
R21
5 0
RES, 0, 5%, 0.125 W,
0805
0805 CRCW08050000Z0EA Vishay-Dale
R7 1 47k
RES, 47 k, 5%, 0.125 W,
0805
0805 CRCW080547K0JNEA Vishay-Dale
R16, R17 2 4.7k
RES, 4.7 k, 5%, 0.125 W,
0805
0805 CRCW08054K70JNEA Vishay-Dale
SH-J1, SH-
JP1, SH-
JP5, SH-
JP6, SH-
JP7, SH-
JP8, SH-
JP9, SH-
JP10, SH-
JP11, SH-
JP12
10 1x2
Shunt, 100mil, Gold
plated, Black
Shunt
SNT-100-BK-G
Alternate part number:
969102-0000-DA
Samtec
SW1, SW2 2
Switch, SPST-NO, Off-
Mom, 0.02 A, 15 VDC, TH
6x6mm EVQ-11A04M Panasonic
SW3, SW4,
SW5
3
Switch, DPST, Slide, Off-
On, 1 Pos, 0.15A, 30V, TH
9.65x7.12mm 78F01T Grayhill
C8, C9 0 12pF
CAP, CERM, 12 pF, 50 V,
+/- 5%, C0G/NP0, 0805
0805 C0805C120J5GACTU Kemet
Hardware
www.ti.com
86 MSP430™ Hardware Tools SLAU278AG – MAY 2009 – REVISED DECEMBER 2020
Submit Document Feedback
Copyright © 2020 Texas Instruments Incorporated
