Table B-35. MSP-TS430PZ100 Bill of Materials
Pos. Ref Des
No. per
Board
Description Digi-Key Part No. Comment
1 C1, C2 0 12pF, SMD0805 DNP
1b C3, C4 0 47pF, SMD0805
DNP: Only recommendation.
Check your crystal spec.
2 C6, C7 1 10uF, 10V, Tantal Size B 511-1463-2-ND DNP: C6
3 C5 1 100nF, SMD0805 478-3351-2-ND
4 C8 1 10nF, SMD0805 478-1383-2-ND
5 C9 1 470nF, SMD0805 478-1403-2-ND
6 D1 1 yellow LED, TH, 3mm, T1 511-1251-ND
7 J1, J2, J3, J4 0 25-pin header, TH
DNP: Headers and
receptacles enclosed with
kit.Keep vias free of solder.
SAM1029-25-ND : Header
SAM1213-25-ND : Receptacle
8 J5 1 3-pin header, male, TH SAM1035-03-ND
9 J6, J7 2 2-pin header, male, TH SAM1035-02-ND place jumper on header
10 2 Jumper 15-38-1024-ND Place on: J6, J7
11 JTAG 1 14-pin connector, male, TH HRP14H-ND
12 BOOTST 0 10-pin connector, male, TH DNP: Keep vias free of solder
13 Q1, Q2 0 Crystal
Q1: Micro Crystal MS1V-T1K
32.768kHz, C(Load) = 12.5pF
DNP: Keep vias free of solder
14 R3 1 330 Ω, SMD0805 541-330ATR-ND
15
R1, R2, R4,
R8, R9, R10,
R11, R12
3 0 Ω, SMD0805 541-000ATR-ND DNP: R4, R9, R10, R12
16 R5 1 47k Ω, SMD0805 541-47000ATR-ND
17 U1 1
Socket: IC201-1004-008 or
IC357-1004-53N
Manuf.: Yamaichi
18 PCB 1 82 × 90 mm 2 layers
19
Adhesive
Plastic feet
4 ~6mm width, 2mm height
for example, 3M Bumpons
Part No. SJ-5302
Apply to corners at bottom
side
20 MSP430 2 MSP430FG4619IPZ
DNP: enclosed with kit
supplied by TI
Hardware www.ti.com
142 MSP430™ Hardware Tools SLAU278AG – MAY 2009 – REVISED DECEMBER 2020
Submit Document Feedback
Copyright © 2020 Texas Instruments Incorporated
